Table 35. I/O Port Register Map And Reset Values - STMicroelectronics ST72361 Auto Series Manual

ST72361xx-Auto
Table 35.
Address
(Hex.)
Reset value
of all IO port registers
0000h
0001h
0002h
0003h
0004h
0005h
0006h
0007h
0008h
0009h
000Ah
000Bh
000Ch
000Dh
000Eh
000Fh
0010h
0011h
I/O port register map and reset values
Register
7
label
0 0
PADR
PADDR MSB
PAOR
PBDR
PBDDR MSB
PBOR
PCDR
PCDDR MSB
PCOR
PDDR
PDDDR MSB
PDOR
PEDR
PEDDR MSB
PEOR
PFDR
PFDDR MSB
PFOR
Doc ID 12468 Rev 3
6 5 4
0 0
3 2 1
0 0 0
I/O ports
0
0
LSB
LSB
LSB
LSB
LSB
LSB
79/279
