2.8 Coolant Pump Toothed Belt, Removing
and Installing
Special tools and workshop equipment required
♦ Torque Wrench 1331 Insert - Ring Wrench - 12mm - T10360-
♦ Torque Wrench 1410 - VAG1410-
Removing
– Drain the coolant. Refer to
⇒ 1.3 Coolant, Draining and Filling , page 217
– Remove the air filter housing. Refer to
⇒ 3.2 Air Filter Housing, Removing and Installing ,
page 294 .
– Free up the wiring harness -1 and 2- from the air guide pipe.
– Loosen the screw-type clamp -3-.
– Remove the bolts -arrows-.
– Loosen the hose clamp -arrow- and remove the charge air
hose -1- with the air guide pipe downward.
– Remove the bolt -arrow- on the left and right.
– Unclip and remove the lower section -1- of the air duct.
