Volkswagen 2015 Golf GTI Technical Specifications

2015 Golf GTI
Technical Specifications
Golf GTI
ENGINE
Type 2.0L inline four cylinder, 16V,
turbocharged/intercooled, TSI
Bore 3.25 in
Stroke 3.65 in
Displacement 121 cu in
Compression Ratio 9.6:1
Horsepower (SAE) @ rpm 210 @ 4500
Horsepower: Performance 220 @ 4700
Maximum torque, lb-ft @ rpm 258 @ 1500
Maximum torque: Performance 258 @ 1500
Fuel Requirement Premium unleaded recommended
ENGINE DESIGN
Arrangement Front mounted, transverse
Cylinder block Cast iron
Crankshaft Forged steel, five main bearings
Cylinder head Aluminum alloy, crossflow
Valvetrain Double overhead camshaft, chain driven, four valves
per cylinder, maintenance-free hydraulic lifters,
variable intake and exhaust timing, variable exhaust-
valve lift
DRIVETRAIN
Driven wheels Front-wheel drive
Transmission Gear Ratios:1 1st
2nd
3rd
4th
5th
6th
Reverse 4.55
Final I
Final II
CAPACITIES
Fuel Tank 13.2 gal
STEERING
Rack and pinion: electric power assist
Type
Turns (lock to lock) 2.10
Turning Circle (curb to curb) 35.8 ft
Ratio Variable
INTERIOR VOLUME - SAE
EPA Class Compact
Seating Capacity Five
Passenger Volume 93.5 cu ft
Cargo Volume, trunk 22.8 cu ft
Cargo Volume, seats down 52.7 cu ft
Front
Volume 51.2 cu ft
Headroom (in/mm) 38.4/975
Shoulder room 2D/4D (in/mm) 55.9/1420
Legroom (in/mm) 41.2/1046
BODY, CHASSIS AND SUSPENSION
Unitary construction, bolt-on front
Type
fenders, two solid mounted subframes
Body Material Steel stampings
Front Suspension Strut-type with lower control arms, coil springs, telescopic dampers, 24-mm-diameter
anti-roll bar
Rear Suspension Multilink with coil springs, telescopic
dampers, 20-mm-diameter anti-roll bar
Power assisted, dual circuit, 12.3 x 1.2-in
Brakes
vented front discs and 10.7 x 0.4-in solid
rear discs
Power assisted, dual circuit, 13.4 x 1.2-in
Brakes: Performance
vented front discs and 12.2 x 0.9-in vented
rear discs
Standard, all four wheels, three-channel
Anti-Lock Braking System
with electronic brake pressure
distribution
Standard Electronic Stability Control
Stability Control
(ESC)
Parking Brake Mechanical
Wheels/Tires 18-in x 7.5J aluminum-alloy wheels
225/40 R18 92H all-season tires
225/40 R18 summer tires (optional)
Drag Coefficient 0.31
82.5 mm
92.8 mm
1984 cc
(155 kW @ 4500)
(162 kW @ 4700)
(350 Nm @ 1500)
(350 Nm @ 1500)
Manual Automatic
3.76 2.92
2.08 1.79
1.46 1.14
1.08 0.78
1.09 0.80
0.91 0.64
3.26
3.24 4.77
2.62 3.44
50 L
10.9 m
Rear
42.3 cu ft
38.1/967
53.9/1370
35.6/903
1
