Baumer OX200 Operating Manual page 37

Baumer
MessageType: Z profile
Field name
MessageType
ConfigMode active
Time is synced by NTP
Values are valid
Alarm
Quality
MeasurementRateHz
TimestampSeconds
TimestampMicroSeconds
EncoderValue
ProfileLength
Profile_x_coordinate_[0]
Profile_z_coordinate_[0]
...
Profile_x_coordinate_[n]
Profile_z_coordinate_[n]
OX200 | V2
Offset Value Data type Description
0 1 UInt8
1 Bool
2 Bool
3 Bool
4 Bool
5 UInt8
6 Float32
10 UInt32
14 UInt32
18 UInt16
20 UInt32
24 UInt16
26 UInt16
24+4*n UInt16
24+4*n UInt16
+2
Operating Manual
Description
0 = Measurement results
1 = Z profile
2 = I profile
3 = Z-I profile
Number of profile points.
n = ProfileLength - 1
