3 | Description
UDP body The following table provides an overview of the UDP body.
The content of the UDP body depends on the MessageType field.
MessageType: Measurement results
Field name
MessageType
ConfigMode active
Time is synced by NTP
Values are valid
Alarm
Quality
Switching Output 1
Switching Output 2
MeasurementValue1
MeasurementValue2
MeasurementValue3
MeasurementValue4
MeasurementValue5
MeasurementValue6
MeasurementValue7
MeasurementRateHz
TimestampSeconds
TimestampMicroSeconds
EncoderPosition
36
Offset Value
0 0
1
2
3
4
5
6
7
8
12
16
20
24
28
32
36
40
44
48
Operating Manual
Data type Description
UInt8 0 = Measurement results
1 = Z profile
2 = I profile
3 = Z-I profile
Bool
Bool
Bool
Bool
UInt8
Bool
Bool
Float32 The content and order of the
measurement results corres-
Float32
ponds to the order in the
Float32
measured value array.
Float32
Float32
Float32
Float32
Float32
UInt32
UInt32
UInt16
