3 | Description
3.3.2

Profinet [OXM]

Profinet (Process Field Network) is an open Industrial Ethernet standard from PI (Profibus and
Profinet International) and is based on existing IT standards (such as UDP, for example).
For information regarding the commissioning of Profinet, see
the PLC [OXM]
Data is organised in modules in Profinet. This means that the data is summarised in logical
groups and mapped to the existing interfaces. The mapping and evaluation of the data in the
PLC must be configured with the respective manufacturer-specific tool.
Mapping of the sensor functions to the Profinet modules
The following tables give an overview of the arrangement of the sensor functions (data ele-
ments) in the individual Profinet modules. The data elements are organised from sub-modules
for easier evaluation.
Module: Con- Module ID: 3
n
trol and
Preselected in slot 1
n
status
Input data sensor > PLC:
Sub-module ID
1
2
3
4
5
6
7
8
9
10
11
Parameter:
Name
Parameter setup
22
[} 54].
Data element
Parametrisation mode
Time synchronisation
Valid values
Alarm state
Quality status
Measurement rate (Hz)
Time stamp (s)
Time stamp (µs)
Encoder value
Output 1
Output 2
Sub-mod- Index
ule
1 1
Operating Manual
Profinet: Integrating the sensor in
Data type Byte off-
set
UInt8 0
Data type
UInt8
UInt8
UInt8
UInt8
UInt8
Float32
UInt32
UInt32
UInt16
UInt8
UInt8
Default Change-
value able
1 Yes
OX200 | V2
Baumer
Visible
Yes
