Description; Sensor; Structure; Ill. 2 Ox200 - Structure - Baumer OX200 Operating Manual

3 |

Description

3 Description
3.1

Sensor

3.1.1

Structure

Ill. 2: OX200 – Structure
1
3
10
Electrical connection
M12 12-pin, A-coded, male
Sensor LEDs
Operating Manual
1
2
2 Ethernet connection
M12 8-pin, X-coded, female
4 Front panel
Baumer
OX200 | V2
