Baumer
− NTP
− Time Server
Process Interface
− Realtime Ethernet
− Modbus TCP
− OPC UA
− UDP Streaming
Web Interface & Firmware
− Security
− Factory Reset
− Settings Reset
OX200 | V2
Activation/deactivation of the NTP synchronisation:
n
When NTP is activated, the sensor synchronises its internal
clock with a defined time server of the network.
Input Time Server of the network.
n
Activation/deactivation of the process interfaces.
n
If deactivated, the sensor no longer responds to queries via
n
this protocol.
The protocols can be used in parallel.
n
Profinet is deactivated on delivery so that the sensor can be
n
put into operation without control.
Activation/deactivation of Profinet IO.
n
Activation/deactivation of Ethernet/IP.
n
After the sensor has been activated and restarted, the IP ad-
n
dress of the sensor is set to 0.0.0.0 so that automatic detec-
tion of the sensor is possible within each infrastructure.
Activation/deactivation of Modbus TCP.
n
See also
Modbus TCP [OXM]
n
Activation/deactivation of OPC UA.
n
See also
OPC UA [OXM]
n
Activation/deactivation of UDP Streaming.
n
See also
UDP
[} 34].
n
Display of the web interface software and firmware version.
n
Uploading updated web interface software (.img format) and
n
firmware (.fup format).
▪ It is possible to install a more recent revision of the firmware
on the sensor, as long as the compatibility of the firmware is
not excluded by the release notes.
▪ Downgrading the firmware is also possible. However, only
down to the firmware with which the sensor was delivered.
Activation/deactivation of Password Protection.
n
Resetting the sensor to factory settings.
n
Resetting the sensor settings. The IP address is not reset in
n
this process.
Operating Manual
Web interface operation
[} 25].
[} 29].
|
9
107
