Resetting Flex Mount

Resetting the Flex Mount sets the angle to 0° and the distance to the measurement range end
Sde. As soon as the function is reset, the field of view is equal to the maximum field of view.
To reset Flex Mount, proceed as follows:
Instruction:
a) In the menu, select the Parametrization | Global Parametrization mode.
b) In the Global Parameters window, proceed to Field of View | Flex Mount.
c) Click the Reset button.
9.2.12

Setting the limits of the field of view

You can use the Field of View Limits function to set that only part of the camera is read out,
thus reducing the field of view (FoV). The profile points outside the set field of view limit are ig-
nored. The function does not affect the width of the laser line.
With the Set FOV to Max selection, you reset all limits of the field of view back to the standard
settings (maximum field of view).
INFO
As soon as you use the Flex Mount function to teach in a new reference surface, the field of
view is maximised.
The Field of View Limits function is only recommended if you want to optimise the measure-
ment rate of the sensor. The Region of Interest Limits function in the Measurement Tools
Parametrization mode is available for masking disruptive reflexes or undesired objects. You
can set individual evaluation range limits for each stored measurement tool.
