Baumer OX200 Operating Manual page 27

Baumer
Address
40 ... 88
(49 bytes)
Address
200 ... 223
(24 bytes)
OX200 | V2
Data element Data type Access
Device info
String[9]
String[65]
String[20]
String[2]
Data element Data type
All Measure-
ment Values
Status UInt16
Quality UInt8
Output UInt8
Measured value Float32
1
Measured value Float32
2
Measured value Float32
3
Offset
Read
0 ... 3
4 High byte
4 Low byte
5 ... 36
37 ... 46
47 ... 48
Access Offset
Read
0
1
2
3
4
5
6
Operating Manual
Description
Description
Exit active parametrisation
mode by writing a random
value.
Product ID
Sensor type
Serial number
Padding
Description
Status
Bit 0 Parametrisation
mode is active.
Bit 1 Time is synchronised
with the NTP server.
Bit 2 Values are valid
(measured values
may be interpreted).
Bit 3 Alarm is active.
Quality information on the current
measured values.
0 OK
1 Weak signal.
2 No signal.
Outputs
Bit 0 Status of binary out-
put 1.
Bit 1 Status of binary out-
put 2.
Measured value parametrised in
advance on the web interface.
Low 2 Bytes
High 2 Bytes
Measured value parametrised in
advance on the web interface.
Low 2 Bytes
High 2 Bytes
Measured value parametrised in
advance on the web interface.
| 3
