3
|
Description
Identification
The following table provides an overview of the Identification folder in the function tree.
OPC UA command
ProductId
Lock
The following table provides an overview of the Lock folder in the function tree.
OPC UA command
BreakLock
ExitLock
InitLock
Locked
LockingClient
LockingUser
RemainingLockTime
RenewLock
Measurement The following table provides an overview of the Measurement folder in the function tree.
OPC UA command
AlarmOutput
ConfigModeActive
EncoderValue
MeasurementRate
MeasurementValue1
MeasurementValue2
MeasurementValue3
MeasurementValue4
MeasurementValue5
MeasurementValue6
MeasurementValue7
Quality
SwitchingOutput1
SwitchingOutput2
TimeStampSec
TimeStampUSec
TimeSynchronised
MeasurementValuesBlock
30
Sensor command
Item/order number of the sensor
Sensor command
Not implemented.
Deactivate parametrisation mode.
Unlock the sensor (initiate the parametrisation mode).
Indicates whether the sensor is currently in the parametrisa-
tion mode.
Specifies which interface was used to set the sensor to
parametrisation mode.
Not implemented.
Not implemented.
Not implemented.
Sensor command
Alarm output active (yes/no)
The measured value was determined when the sensor was
in parametrisation mode.
Value of the connected encoder
Measurement rate (in Hz)
Measured value 1
Measured value 2
Measured value 3
Measured value 4
Measured value 5
Measured value 6
Measured value 7
Signal quality
0 = good signal (valid)
n
1 = weak signal (uncertain)
n
2 = no signal (invalid)
n
Switching output 1 active (yes/no)
Switching output 2 active (yes/no)
Time stamp of the measurement (in s)
Time stamp of the measurement (in µs)
Time synchronisation active (yes/no)
Last 100 measurement results. In the case of new measure-
ment results, the oldest measurement result disappears.
Operating Manual
Baumer
OX200 | V2
