60 –

Sunroof

1

Panoramic roof

1.1

Summary of components of panoramic roof

1 - Window of panoramic roof
2 - Glue sealing material
3 - Gasket all the way around
4 - Body sheet profiles
5 - Fixing bolts
1.2

Removing and installing panoramic roof

WARNING
Wear protective goggles and gloves when cutting hardened
PUR glue sealing material and when working with window and
cutting cords.
Panoramic roof cannot be used again after being cut out. The
all-round seal is damaged when cutting which cannot be re‐
placed. At the same time, the moulding on the contact surface
of the panoramic roof is also damaged.
Rapid NH 2014 ➤ , Rapid Spaceback 2014 ➤
Body Work - Edition 10.2018
127
1. Panoramic roof
