Parameter Descriptions
8-14 Configurable Control Word CTW
Option: Function:
[231] Power Limit
Mot.
[232] Power Limit See parameter group 4-8* Power Limit. Use
Gen. this option in the generating mode only.
[233] Power Limit See parameter group 4-8* Power Limit. Use
Both this option in both the motor and the
generating modes.

8-17 Configurable Alarm and Warningword

The configurable alarm and warning word has 16 bits (0–15).
Each of those bits can be configured to any of the following
options.
Option:
[0] Off
*
[1] 10 Volts low warning
[2] Live zero warning
[3] No motor warning
[4] Mains phase loss warning
[5] DC link voltage high warning
[6] DC link voltage low warning
[7] DC overvoltage warning
[8] DC undervoltage warning
[9] Inverter overloaded warning
[10] Motor ETR overtemp warning
[11] Motor thermistor overtemp warning
[12] Torque limit warning
[13] Over current warning
[14] Earth fault warning
[17] Controlword timeout warning
[19] Discharge temp high warning
[22] Hoist mech brake warning
[23] Internal fans warning
[24] External fans warning
[25] Brake resistor short circuit warning
[26] Brake powerlimit warning
[27] Brake chopper short circuit warning
[28] Brake check warning
[29] Heatsink temperature warning
[30] Motor phase U warning
[31] Motor phase V warning
[32] Motor phase W warning
[34] Fieldbus communication warning
[36] Mains failure warning
[40] T27 overload warning
[41] T29 overload warning
[45] Earth fault 2 warning
[47] 24V supply low warning
[58] AMA internal fault warning
[59] Current limit warning
[60] External interlock warning
[61] Feedback error warning
[62] Frequency max warning
MG33MP02
Programming Guide
8-17 Configurable Alarm and Warningword
The configurable alarm and warning word has 16 bits (0–15).
Each of those bits can be configured to any of the following
options.
Option:
[64]
[65]
[66]
[68]
[73]
[76]
[77]
[78]
[89]
[163]
Function:
[165]
[10002]
[10004]
[10007]
[10008]
[10009]
[10010]
[10011]
[10012]
[10013]
[10014]
[10016]
[10017]
[10022]
[10026]
[10027]
[10028]
[10029]
[10030]
[10031]
[10032]
[10033]
[10034]
[10036]
[10037]
[10038]
[10039]
[10045]
[10046]
[10047]
[10048]
[10049]
[10060]
[10061]
[10063]
[10065]
[10067]
[10068]
[10069]
Danfoss A/S © 10/2018 All rights reserved.
Voltage limit warning
Controlboard overtemp warning
Heatsink temp low warning
Safe stop warning
Safe stop autorestart warning
Power unit setup warning
Reduced powermode warning
Tracking error warning
Mech brake sliding warning
ATEX ETR cur limit warning
ATEX ETR freq limit warning
Live zero error alarm
Mains phase loss alarm
DC overvoltage alarm
DC undervoltage alarm
Inverter overload alarm
ETR overtemperature alarm
Thermistor overtemp alarm
Torque limit alarm
Overcurrent alarm
Earth fault alarm
Short circuit alarm
CTW timeout alarm
Hoist brake alarm
Brake powerlimit alarm
Brakechopper shortcircuit alarm
Brake check alarm
Heatsink temp alarm
Phase U missing alarm
Phase V missing alarm
Phase W missing alarm
Inrush fault alarm
Fieldbus com faul alarm
Mains failure alarm
Phase imbalance alarm
Internal fault
Heatsink sensor alarm
Earth fault 2 alarm
Powercard supply alarm
24V supply low alarm
1.8V supply low alarm
Speed limit alarm
Ext interlock alarm
Feedback error alarm
Mech brake low alarm
Controlboard overtemp alarm
Option config changed alarm
Safe stop alarm
Powercard temp alarm
Function:
3 3
