Parameter Descriptions
5-78 Term 27/29 Encoder Sim
Option:
3 3

3.6.8 5-8* I/O Options

5-80 AHF Cap Reconnect Delay
Range:
25 s [1 - 120
*
s]

3.6.9 5-9* Bus-controlled

This parameter group selects digital and relay outputs via a
fieldbus setting.
5-90 Digital & Relay Bus Control
Range:
0 [0 - 2147483647 ] This parameter holds the state of the
*
Bit 0 Digital output terminal 27
Bit 1 Digital output terminal 29
Bit 2 Digital output terminal X 30/6
Bit 3 Digital output terminal X 30/7
Bit 4 Relay 1 output terminal
Bit 5 Relay 2 output terminal
Bit 6 Option B relay 1 output terminal
Bit 7 Option B relay 2 output terminal
Bit 8 Option B relay 3 output terminal
Bit 9–15 Reserved for future terminals
Bit 16 Option C relay 1 output terminal
Bit 17 Option C relay 2 output terminal
Bit 18 Option C relay 3 output terminal
Bit 19 Option C relay 4 output terminal
Bit 20 Option C relay 5 output terminal
Bit 21 Option C relay 6 output terminal
Bit 22 Option C relay 7 output terminal
Bit 23 Option C relay 8 output terminal
Bit 24–31 Reserved for future terminals
Table 3.22 Bus-controlled Digital Outputs and Relays
134
VLT
Function:
parameter 3-22 Master Scale Numerator,
parameter 3-23 Master Scale Denominator,
parameter 17-72 Position Unit Numerator and
parameter 17-73 Position Unit Denominator
Function:
Guarantees a minimum off-time for the
capacitors. The timer starts once the AHF
capacitor disconnects and has to expire before
the output is allowed to be on again. It only
turns on again if the frequency converter
power is 20–30%.
Function:
digital outputs and relays that is
controlled by bus.
A logical 1 indicates that the output is
high or active.
A logical 0 indicates that the output is
low or inactive.
Danfoss A/S © 10/2018 All rights reserved.
®
AutomationDrive FC 301/302
5-93 Pulse Out #27 Bus Control
Range:
0 % [0 -
*
100 %]
5-94 Pulse Out #27 Timeout Preset
Range:
0 % [0 -
*
100 %]
5-95 Pulse Out #29 Bus Control
Range:
0 % [0 -
*
100 %]
5-96 Pulse Out #29 Timeout Preset
Range:
0 % [0 -
*
100 %]
5-97 Pulse Out #X30/6 Bus Control
Range:
0 % [0 -
*
100 %]
5-98 Pulse Out #X30/6 Timeout Preset
Range:
0 % [0 -
*
100 %]

3.7 Parameters: 6-** Analog In/Out

3.7.1 6-0* Analog I/O Mode

The analog inputs can be allocated to be either voltage
(FC 301: 0–10 V, FC 302: 0 to ±10 V) or current input (FC
301/FC 302: 0/4–20 mA).
Function:
Set the output frequency transferred to
output terminal 27 when the terminal is
configured as [45] Bus Controlled in
parameter 5-60 Terminal 27 Pulse Output
Variable.
Function:
Set the output frequency transferred to output
terminal 27 when the terminal is configured as
[48] Bus Ctrl Timeout in parameter 5-60 Terminal
27 Pulse Output Variable and a timeout is
detected.
Function:
Set the output frequency transferred to
output terminal 29 when the terminal is
configured as [45] Bus Controlled in
parameter 5-63 Terminal 29 Pulse Output
Variable.
Function:
Set the output frequency transferred to output
terminal 29 when the terminal is configured as
[48] Bus Ctrl Timeout in parameter 5-63 Terminal
29 Pulse Output Variable and a timeout is
detected.
Function:
Set the output frequency transferred to
output terminal X30/6 when the terminal is
configured as [45] Bus ctrl. in
parameter 5-66 Terminal X30/6 Pulse Output
Variable.
Function:
Set the output frequency transferred to output
terminal X30/6 when the terminal is configured
as [48] Bus Ctrl Timeout in
parameter 5-66 Terminal X30/6 Pulse Output
Variable and a timeout is detected.
MG33MP02
