5-60 Terminal 27 Pulse Output Variable

Option: Function:
[102] Feedback
[103] Motor Current
[104] Torque rel to limit
[105] Torq relate to rated
[106] Power
[107] Speed
[108] Torque
[109] Max Out Freq
[119] Torque % lim

5-62 Pulse Output Max Freq #27

Range: Function:
Size [0 - 110000 Set the maximum frequency for
related Hz] terminal 27 corresponding to the
*
output variable selected in
parameter 5-60 Terminal 27 Pulse
Output Variable.

5-63 Terminal 29 Pulse Output Variable

Option: Function:
NOTICE
This parameter is available for FC
302 only.
[0] No operation Select the display output for terminal
29.
[45] Bus ctrl.
[48] Bus ctrl., timeout
[51] MCO controlled
NOTICE
[97] Reference After
Ramp
This option is available only with
software version 48.XX.
Actual speed reference after the ramp.
Use this output as master signal for
speed synchronization of follower
frequency converters. The reference is
set in parameter 16-48 Speed Ref. After
Ramp [RPM].
NOTICE
[99] Virtual Master
Speed
This option is available only with
software version 48.XX.
Virtual master signal for controlling
the speed or position of the followers.
[100] Output frequency
[101] Reference
[102] Feedback
[103] Motor Current
[104] Torque rel to limit
MG33MP02
Programming Guide
5-63 Terminal 29 Pulse Output Variable
Option:
[105] Torq relate to
rated
[106] Power
[107] Speed
[108] Torque
[109] Max Out Freq
[119] Torque % lim
5-65 Pulse Output Max Freq #29
Range:
Size
related
*

5-66 Terminal X30/6 Pulse Output Variable

Select the variable for readout on terminal X30/6.
This parameter is active when VLT
is installed in the frequency converter.
Same options and functions as parameter group 5-6* Pulse
Outputs.
Option:
[0] No operation
[45] Bus ctrl.
[48] Bus ctrl., timeout
[51] MCO controlled
[97] Reference After
Ramp
[99] Virtual Master Speed
[100] Output frequency
[101] Reference
[102] Feedback
[103] Motor Current
[104] Torque rel to limit
[105] Torq relate to rated
[106] Power
Danfoss A/S © 10/2018 All rights reserved.
Function:
Function:
[0 - 110000 Set the maximum frequency for
Hz] terminal 29 corresponding to the
output variable set in
parameter 5-63 Terminal 29 Pulse
Output Variable.
®
General Purpose I/O MCB 101
Function:
NOTICE
This option is available only
with software version 48.XX.
Actual speed reference after the
ramp. Use this output as master
signal for speed synchronization of
follower frequency converters. The
reference is set in
parameter 16-48 Speed Ref. After
Ramp [RPM].
NOTICE
This option is available only
with software version 48.XX.
Virtual master signal for controlling
the speed or position of the
followers.
