Parameter Descriptions

16-82 Fieldbus REF 1

Range: Function:
0 [-200 - 200 ] View the two-byte word sent with the control
*
word form the Bus-Master to set the reference
value.
For more information, refer to the relevant
fieldbus manual.

16-83 Fieldbus Pos. REF

Range:
0 CustomRea- [-2147483648 -
doutUnit2 2147483647
*
CustomRea-
doutUnit2]
16-84 Comm. Option STW
Range: Function:
0 [0 - 65535 ] Show the status word of the extended fieldbus
*
communication option.
For more information, refer to the relevant
fieldbus manual.
16-85 FC Port CTW 1
Range: Function:
0 [0 - View the 2-byte control word (CTW) received
*
65535 ] from the fieldbus master. Interpretation of the
control word depends on the fieldbus option
installed and the control word profile selected
in parameter 8-10 Control Word Profile.
16-86 FC Port REF 1
Range: Function:
0 [-200 - View the 2-byte status word (STW) sent to the
*
200 ] fieldbus master. Interpretation of the status word
depends on the fieldbus option installed and the
control word profile selected in
parameter 8-10 Control Word Profile.

16-87 Bus Readout Alarm/Warning

Range: Function:
0 [0 - 65535 ] Alarm and warning numbers in hex as shown
*
in the alarm log. The high byte contains the
alarm, the low byte contains the warning. The
MG33MP02
Programming Guide
Function:
NOTICE
This parameter is only
valid with software
version 48.XX.
Shows the 32-bit position
reference sent in PCD 2 and
PCD 3. In parameters related
to PCD 2 and PCD 3, select
[1683] Fieldbus Pos REF for the
fieldbus which is used by the
frequency converter. The value
is in position units defined in
parameter group 17-7* Position
Scaling.
Danfoss A/S © 10/2018 All rights reserved.
16-87 Bus Readout Alarm/Warning
Range: Function:
alarm number is the 1st one that occurred
after the last reset.
16-89 Configurable Alarm/Warning Word
Range: Function:
0 [0 - 65535 ] This alarm/warning word is configured in
*
parameter 8-17 Configurable Alarm and
Warningword to match the actual requirements.

3.16.7 16-9* Diagnosis Readouts

NOTICE
When using MCT 10 Set-up Software, the readout
parameters can only be read online, that is as the actual
status. This means that the status is not stored in the
MCT 10 Set-up Software file.
16-90 Alarm Word
Range: Function:
0 [0 - 4294967295 ] Show the alarm word sent via the serial
*
communication port in hex code.
16-91 Alarm Word 2
Range: Function:
0 [0 - 4294967295 ] View the alarm word sent via the serial
*
communication port in hex code.
16-92 Warning Word
Range: Function:
0 [0 - 4294967295 ] Show the warning word sent via the
*
serial communication port in hex code.
16-93 Warning Word 2
Range: Function:
0 [0 - 4294967295 ] View the warning word sent via the serial
*
communication port in hex code.
16-94 Ext. Status Word
Range: Function:
0 [0 - 4294967295 ] Returns the extended warning word sent
*
via the serial communication port in hex
code.
16-95 Ext. Status Word 2
Range:
0 [0 - 4294967295 ]
*
3
Function:
