Parameter Descriptions
•
[0]: Power card 1 (the master power card in a
parallel frequency converter, or the only power
card in a frequency converter with a single
inverter section).
•
[1]: Power card 2 (inverter connection in a parallel
3 3
frequency converter).
•
[2]: Power card 3 (inverter connection in a parallel
frequency converter).
•
[3]: Power card 4 (inverter connection in a parallel
frequency converter).
•
[4]: Power card 5 (rectifier connection in a parallel
frequency converter).
•
[5]: Power card 6 (rectifier connection in a parallel
frequency converter).
•
[6]: Power card 7 (rectifier connection in a parallel
frequency converter).
•
[7]: Power card 8 (rectifier connection in a parallel
frequency converter).
•
[8]: Inrush card (optional).
•
[9]: Fan power card 1 (optional).
•
[10]: Fan power card 2 (optional).
43-00 Component Temp.
Range:
0 °C [-128 -
*
127 °C]
Range:
0 °C [-128 -
127 °C]
*
43-02 Component SW ID
Range:
0 [0 - 20 ] Shows the software version of the installed option.
*
250
VLT
Function:
NOTICE
This parameter is valid for FC 302 only.
Shows the temperature of a system component.
The elements of the array reference local PCB
temperature sensor measurements.
Parameter 16-31 System Temp. uses all elements
in this array to calculate the system
temperature.
Function:
NOTICE
This parameter is valid for FC 302 only.
Shows the temperature of an auxiliary
component. The elements of the array reference
the temperature measurements from the NTC
temperature sensors connected to hardware
components in the frequency converter. Refer to
the operating guide for specifications of
temperature sensor placement.
Function:
Danfoss A/S © 10/2018 All rights reserved.
®
AutomationDrive FC 301/302

3.31.2 43-1* Power Card Status

This parameter group contains read-only information on
the power card status. All parameters in this group are
arrays:
•
[0]: Power card 1 (the master power card in a
parallel frequency converter, or the only power
card in a frequency converter with a single
inverter section).
•
[1]: Power card 2 (inverter connection in a parallel
frequency converter).
•
[2]: Power card 3 (inverter connection in a parallel
frequency converter).
•
[3]: Power card 4 (inverter connection in a parallel
frequency converter).
•
[4]: Power card 5 (rectifier connection in a parallel
frequency converter).
•
[5]: Power card 6 (rectifier connection in a parallel
frequency converter).
•
[6]: Power card 7 (rectifier connection in a parallel
frequency converter).
•
[7]: Power card 8 (rectifier connection in a parallel
frequency converter).

3.31.3 43-10 HS Temp. ph.U

43-10 HS Temp. ph.U
Range:
0 °C [-128 -
*
127 °C]
43-11 HS Temp. ph.V
Range:
0 °C [-128 -
*
127 °C]
Function:
NOTICE
This parameter is valid for FC 302 only.
Shows the heat sink temperature at the
location of the phase U IGBT power module.
This measurement is not available in all
enclosure sizes. Parameter 16-34 Heatsink Temp.
uses the value in this parameter.
Function:
NOTICE
This parameter is valid for FC 302 only.
Shows the heat sink temperature at the
location of the phase V IGBT power module.
This measurement is not available in all
enclosure sizes. Parameter 16-34 Heatsink Temp.
uses the value in this parameter.
