Danfoss VLT AutomationDrive FC 302 Programming Manual page 128

Parameter Descriptions
5-40 Function Relay
Option:
[64] Comparator 4
3 3
[65] Comparator 5
[70] Logic rule 0
[71] Logic rule 1
[72] Logic rule 2
[73] Logic rule 3
[74] Logic rule 4
[75] Logic rule 5
[80] SL digital output
A
[81] SL digital output
B
[82] SL digital output
C
[83] SL digital output
D
126
®
VLT AutomationDrive FC 301/302
Function:
true, the output goes high. Otherwise,
it is low.
See parameter group 13-1*
Comparators. If comparator 4 in SLC is
true, the output goes high. Otherwise,
it is low.
See parameter group 13-1* Smart Logic
Control. If comparator 5 in SLC is true,
the output goes high. Otherwise, it is
low.
See parameter group 13-4* Smart Logic
Control. If logic rule 0 in SLC is true,
the output goes high. Otherwise, it is
low.
See parameter group 13-4* Smart Logic
Control. If logic rule 1 in SLC is true,
the output goes high. Otherwise, it is
low.
See parameter group 13-4* Smart Logic
Control. If logic rule 2 in SLC is true,
the output goes high. Otherwise, it is
low.
See parameter group 13-4* Smart Logic
Control. If logic rule 3 in SLC is true,
the output goes high. Otherwise, it is
low.
See parameter group 13-4* Smart Logic
Control. If logic rule 4 in SLC is true,
the output goes high. Otherwise, it is
low.
See parameter group 13-4* Smart Logic
Control. If logic rule 5 in SLC is true,
the output goes high. Otherwise, it is
low.
See parameter 13-52 SL Controller
Action. Output A is low on smart logic
action [32]. Output A is high on smart
logic action [38].
See parameter 13-52 SL Controller
Action. Output B is low on smart logic
action [33]. Output B is high on smart
logic action [39].
See parameter 13-52 SL Controller
Action. Output C is low on smart logic
action [34]. Output C is high on smart
logic action [40].
See parameter 13-52 SL Controller
Action. Output D is low on smart logic
action [35]. Output D is high on smart
logic action [41].
Danfoss A/S © 10/2018 All rights reserved.
5-40 Function Relay
Option: Function:
[84] SL digital output See parameter 13-52 SL Controller
E Action. Output E is low on smart logic
action [36]. Output E is high on smart
logic action [42].
[85] SL digital output See parameter 13-52 SL Controller
F Action. Output F is low on smart logic
action [37]. Output F is high on smart
logic action [43].
NOTICE
[96] Reverse After
Ramp
This option is available only with
software version 48.XX.
See the description in
chapter 3.6.3 5-3* Digital Outputs.
NOTICE
[98] Virtual Master Dir.
This option is available only with
software version 48.XX.
See the description in
chapter 3.6.3 5-3* Digital Outputs.
[120] Local ref active Output is high when
parameter 3-13 Reference Site = [2] Local
or when parameter 3-13 Reference Site
= [0] Linked to hand auto at the same
time as the LCP is in hand-on mode.
Reference site
set in
parameter 3-13
Reference Site
Reference site:
Local
parameter 3-13 R
eference Site [2]
Local
Reference site:
Remote
parameter 3-13 R
eference Site [1]
Remote
Reference site:
Linked to Hand/
Auto
Hand
Hand⇒off
Auto⇒off
Auto
Table 3.21 Local Reference Active
Local Remote
referenc reference
e active
active [121]
[120]
1 0
0 1
1 0
1 0
0 0
0 1
MG33MP02
