16-37 Inv. Max. Current
Range:
3 3
16-38 SL Controller State
Range:
0 [0 - 100 ] View the state of the event under execution by
*
16-39 Control Card Temp.
Range:
0 °C [0 - 100 °C] View the temperature on the control card,
*

16-40 Logging Buffer Full

Option: Function:
View whether the logging buffer is full (see
chapter 3.15.2 15-1* Data Log Settings). The logging
buffer is never full when parameter 15-13 Logging
Mode is set to [0] Log always.
[0] No
*
[1] Yes
16-41 Performance Measurements
Range:
0 [0 - 2147483647 ]
*

16-42 Service Log Counter

Range:
0 [ 0 - Shows the number of service logs stored in the
*
24 ] ServiceLog file. If the ServiceLog file is full, clear the
logged data by selecting option [5] Clear service logs
in parameter 14-22 Operation Mode. The logged data
is deleted on the next power-up.
16-43 Timed Actions Status
Select the timed actions view.
Option:
[0] Timed Actions Auto
*
[1] Timed Actions Disabled
[2] Constant On Actions
[3] Constant Off Actions
16-44 Speed Error [RPM]
Range:
0 RPM [-30000 - 30000
*
RPM]
212
Function:
data is used for calculation of torque,
motor overload protection, and so on.
Function:
the SL controller.
Function:
stated in °C.
Function:
Function:
Function:
NOTICE
This parameter is only valid with
software version 48.XX.
Shows the difference between the
speed reference and the actual speed.
Danfoss A/S © 10/2018 All rights reserved.
®
VLT AutomationDrive FC 301/302
16-45 Motor Phase U Current
Range:
0 A [0 - 10000 A] Shows the motor phase U
*
16-46 Motor Phase V Current
Range:
0 A [0 - 10000 A] Shows the motor phase V
*
16-47 Motor Phase W Current
Range:
0 A [0 - 10000 A] Shows the motor phase W
*
16-48 Speed Ref. After Ramp [RPM]
Range:
0 RPM
*

16-49 Current Fault Source

Range:
0 [0 - 8 ] Value indicates source of current faults including
*
3.16.4 16-5* Ref. & Feedb.
Function:
16-50 External Reference
Range:
0 [-200 - 200 ] View the total reference, the sum of digital,
*
16-51 Pulse Reference
Range:
0 [-200 - 200 ] View the reference value from programmed
*
Function:
Facilitates monitoring of imbalance in the
motor currents, detection of weak motor
cables or imbalance in motor windings.
Function:
Facilitates monitoring of imbalance in the
motor currents, detection of weak motor
cables or imbalance in motor windings.
Function:
Facilitates monitoring of imbalance in the
motor currents, detection of weak motor
cables or imbalance in motor windings.
Function:
[-30000 - 30000 This parameter specifies the
RPM] reference given to the frequency
converter after the speed ramp.
Function:
short circuit, overcurrent, and imbalance of supply
voltage (from left):
1–4 Inverter
5–8 Rectifier
0 No fault recorded
Function:
analog, preset, fieldbus, and freeze references,
plus catch up and slow down.
Function:
digital inputs. The readout can also reflect the
impulses from an incremental encoder.
current.
RMS
current.
RMS
current.
RMS
