Parameter Descriptions
5-10 Terminal 18 Digital Input
Option:
[72] PID error inverse
[73] PID reset I part
[74] PID enable
3 3
[75] MCO Specific
[78] Reset Maint. Word
[80] PTC Card 1
[91] Profidrive OFF2
[92] Profidrive OFF3
[94] Light Load Detection
[96] Mains Loss
[97] Mains Loss Inverse
[98] Start edge triggered
[100] Safe Option Reset
[107] Target Inverse
[108] Enable Master Offset
[109] Start Virtual Master
[110] Start Homing
[111] Activate Touch
[112] Relative Position
[113] Enable Reference
[114] Sync. to Pos. Mode
[115] Home Sensor
104
®
VLT AutomationDrive FC 301/302
Function:
NOTICE
This option is only available
for software version 48.XX.
NOTICE
This option is only available
for software version 48.XX.
NOTICE
This option is only available
for software version 48.XX.
NOTICE
This option is only available
for software version 48.XX.
NOTICE
This option is only available
for software version 48.XX.
NOTICE
This option is only available
for software version 48.XX.
NOTICE
This option is only available
for software version 48.XX.
NOTICE
This option is only available
for software version 48.XX.
Danfoss A/S © 10/2018 All rights reserved.
5-10 Terminal 18 Digital Input
Option: Function:
NOTICE
[116] Home Sensor Inv.
This option is only available
for software version 48.XX.
NOTICE
[117] Touch Sensor
This option is only available
for software version 48.XX.
NOTICE
[118] Touch Sensor Inv.
This option is only available
for software version 48.XX.
NOTICE
[119] Speed Mode
This option is only available
for software version 48.XX.
[231] Power Limit Mot.
[232] Power Limit Gen.
[233] Power Limit Both

5-11 Terminal 19 Digital Input

Option: Function:
Functions are described in
parameter group 5-1* Digital
Inputs.
[0] No operation
[1] Reset
[2] Coast inverse
[3] Coast and reset inv
[4] Quick stop inverse
[5] DC-brake inverse
[6] Stop inverse
[8] Start
[9] Latched start
[10] Reversing Functions are described in
parameter group 5-1* Digital
Inputs.
[11] Start reversing
[12] Enable start forward
[13] Enable start reverse
[14] Jog
[15] Preset reference on
[16] Preset ref bit 0
[17] Preset ref bit 1
[18] Preset ref bit 2
[19] Freeze reference
[20] Freeze output
[21] Speed up
[22] Speed down
[23] Set-up select bit 0
[24] Set-up select bit 1
