Parameter Lists
5.2.22 31-** Bypass Option
Par. Parameter description
No. #
31-00 Bypass Mode
31-01 Bypass Start Time Delay
31-02 Bypass Trip Time Delay
31-03 Test Mode Activation
31-10 Bypass Status Word
31-11 Bypass Running Hours
31-19 Remote Bypass Activation
Table 5.5
5.2.23 32-** MCO Basic Settings
Par. Parameter description
No. #
32-0* Encoder 2
32-00 Incremental Signal Type
32-01 Incremental Resolution
32-02 Absolute Protocol
32-03 Absolute Resolution
32-04 Absolute Encoder Baudrate X55
32-05 Absolute Encoder Data Length
32-06 Absolute Encoder Clock Frequency
32-07 Absolute Encoder Clock Generation
32-08 Absolute Encoder Cable Length
32-09 Encoder Monitoring
32-10 Rotational Direction
32-11 User Unit Denominator
32-12 User Unit Numerator
32-13 Enc.2 Control
32-14 Enc.2 node ID
32-15 Enc.2 CAN guard
32-3* Encoder 1
32-30 Incremental Signal Type
32-31 Incremental Resolution
32-32 Absolute Protocol
32-33 Absolute Resolution
32-35 Absolute Encoder Data Length
32-36 Absolute Encoder Clock Frequency
32-37 Absolute Encoder Clock Generation
32-38 Absolute Encoder Cable Length
32-39 Encoder Monitoring
32-40 Encoder Termination
32-43 Enc.1 Control
32-44 Enc.1 node ID
32-45 Enc.1 CAN guard
32-5* Feedback Source
32-50 Source Slave
32-51 MCO 302 Last Will
32-52 Source Master
32-6* PID Controller
32-60 Proportional factor
32-61 Derivative factor
MG33MP02
Programming Guide
Default value 4-set-up
[0] Drive All set-ups
30 s All set-ups
0 s All set-ups
[0] Disabled All set-ups
0 N/A All set-ups
0 h All set-ups
[0] Disabled 2 set-ups
Default value 4-set-up
[1] RS422 (5V TTL) 2 set-ups
1024 N/A 2 set-ups
[0] None 2 set-ups
8192 N/A 2 set-ups
[4] 9600 All set-ups
25 N/A 2 set-ups
262 kHz 2 set-ups
[1] On 2 set-ups
0 m 2 set-ups
[0] Off 2 set-ups
[1] No action 2 set-ups
1 N/A 2 set-ups
1 N/A 2 set-ups
[0] No soft changing 2 set-ups
127 N/A 2 set-ups
[0] Off 2 set-ups
[1] RS422 (5V TTL) 2 set-ups
1024 N/A 2 set-ups
[0] None 2 set-ups
8192 N/A 2 set-ups
25 N/A 2 set-ups
262 kHz 2 set-ups
[1] On 2 set-ups
0 m 2 set-ups
[0] Off 2 set-ups
[1] On 2 set-ups
[0] No soft changing 2 set-ups
127 N/A 2 set-ups
[0] Off 2 set-ups
[2] Encoder 2 X55 2 set-ups
[1] Trip 2 set-ups
[1] Encoder 1 X56 2 set-ups
30 N/A 2 set-ups
0 N/A 2 set-ups
Danfoss A/S © 10/2018 All rights reserved.
FC 302 Change Conver-
only during sion index
operation
x TRUE -
x TRUE 0
x TRUE 0
x TRUE -
x FALSE 0
x FALSE 74
x TRUE -
FC 302 Change Conver-
only during sion index
operation
TRUE -
TRUE 0
TRUE -
TRUE 0
FALSE -
TRUE 0
TRUE 0
TRUE -
TRUE 0
TRUE -
TRUE -
TRUE 0
TRUE 0
TRUE -
TRUE 0
TRUE -
TRUE -
TRUE 0
TRUE -
TRUE 0
TRUE 0
TRUE 0
TRUE -
TRUE 0
TRUE -
TRUE -
TRUE -
TRUE 0
TRUE -
TRUE -
TRUE -
TRUE -
TRUE 0
TRUE 0
Type
Uint8
Uint16
Uint16
Uint8
V2
Uint32
Uint8
5 5
Type
Uint8
Uint32
Uint8
Uint32
Uint8
Uint8
Uint32
Uint8
Uint16
Uint8
Uint8
Uint32
Uint32
Uint8
Uint8
Uint8
Uint8
Uint32
Uint8
Uint32
Uint8
Uint32
Uint8
Uint16
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint32
Uint32
