Parameter Descriptions

14-61 Function at Inverter Overload

Option:
[0] Trip
*
3 3
[1] Derate Reduces the motor speed to decrease the load on
14-62 Inv. Overload Derate Current
Range:
95 % [50 -
*
100 %]

3.14.8 14-7* Compatibility

Parameters for compatibility of VLT 3000 and VLT 5000
with FC 300.
14-72 Legacy Alarm Word
Range:
0 [0 - 4294967295 ] Readout of the alarm word
*
14-73 Legacy Warning Word
Range:
0 [0 - 4294967295 ] Readout of the warning word
*
14-74 Leg. Ext. Status Word
Range:
0 [0 - 4294967295 ] Readout of the external status word
*

3.14.9 14-8* Options

14-80 Option Supplied by External 24VDC
Option: Function:
NOTICE
This parameter is only changing function by
performing a power cycle.
[0] No Select [0] No to use the frequency converter's 24 V DC
supply.
[1] Yes Select [1] Yes if a 24 V DC external supply is used to
*
power the option. Inputs/outputs are galvanically
200
Function:
Use in case of steady overload beyond the thermal
limits (110% for 60 s).
Select [0] Trip to make the frequency converter trip
and issue an alarm.
the power section and allowing it to cool down.
Function:
Enter the current level (in % of rated output
current for the frequency converter) when
running with reduced motor speed after load
on the frequency converter has exceeded the
allowable limit (110% for 60 s).
Function:
corresponding to VLT 5000.
Function:
corresponding to VLT 5000.
Function:
corresponding to VLT 5000.
Danfoss A/S © 10/2018 All rights reserved.
®
VLT AutomationDrive FC 301/302
14-80 Option Supplied by External 24VDC
Option:
14-88 Option Data Storage
Range:
0 [0 - 65535 ] This parameter stores information about
*
14-89 Option Detection
Selects the behavior of the frequency converter when a change
in the option configuration is detected.
Option:
[0] Protect Option
*
Config.
[1] Enable Option
Change

3.14.10 14-9* Fault Settings

14-90 Fault Level
This is an array parameter with 26 elements. Each of the bits can
be configured to any of the following options. Use this
parameter to customize fault levels.
Option:
[0] Off
[1] Warning
[2] Trip
[3] Trip Lock
[4] Trip w. delayed
reset
Function:
isolated from the frequency converter when operated
from an external supply.
Function:
options over a power cycle.
Function:
Freezes the current settings and
prevents unwanted changes when
missing or defective options are
detected.
Changes frequency converter settings
and is used when modifying the
system configuration. This parameter
setting returns to [0] Protect Option
Config. after an option change.
Function:
Use [0] Off with caution as it ignores all
warnings and alarms for the selected
source.
Changing a fault level from default option
[3] Trip Lock to [2] Trip leads to the
automatic reset of the alarm. For alarms
involving overcurrent, the frequency
converter has a hardware protection that
issues a 3-minute recovery after 2
consecutive overcurrent incidents. This
hardware protection cannot be overruled.
This option adds a delay between
automatic resets, otherwise it is the same
as option [2] Trip. The delay prevents a
situation where reset is attempted
repeatedly for an overcurrent situation.
Hardware protection of the frequency
converter forces the 3-minute recovery time
after 2 consecutive overcurrents (within a
short time window).
