Parameter Descriptions
13-10 Comparator Operand
Option:
[133] Digital input
DI29
[134] Digital input
3 3
DI32
[135] Digital input
DI33
[150] SL digital
output A
[151] SL digital
output B
[152] SL digital
output C
[153] SL digital
output D
[154] SL digital
output E
[155] SL digital
output F
[160] Relay 1
[161] Relay 2
[162] Relay 3
[163] Relay 4
[164] Relay 5
[165] Relay 6
[166] Relay 7
[167] Relay 8
[168] Relay 9
[180] Local referecnce
active
[181] Remote
reference active
[182] Start command
[183] Drive stopped
[185] Drive in hand
mode
[186] Drive in auto
mode
[187] Start command
given
[190] Digital input
x30/2
[191] Digital input
x30/3
[192] Digital input
x30/4
172
®
VLT AutomationDrive FC 301/302
Function:
Digital input 29 (high=true).
Digital input 32 (high=true).
Digital input 33 (high=true).
Use the result of the SLC output A.
Use the result of the SLC output B.
Use the result of the SLC output C.
Use the result of the SLC output D.
Use the result of the SLC output E.
Use the result of the SLC output F.
Relay 1 is active.
Relay 2 is active.
Active when parameter 3-13 Reference Site
is [2] Local or when
parameter 3-13 Reference Site is [0] Linked
to hand/auto, at the same time as the
LCP is in hand-on mode.
Active when parameter 3-13 Reference Site
is [1] Remote or [0] Linked to hand/auto,
while the LCP is in auto-on mode.
Active when there is an active start
command and no stop command.
A stop command (jog, stop, qstop, coast)
is issued – and not from the SLC itself.
Active when the frequency converter is
in hand-on mode.
Active when the frequency converter is
in auto-on mode.
Danfoss A/S © 10/2018 All rights reserved.
13-10 Comparator Operand
Option: Function:
[193] Digital input
x46/1
[194] Digital input
x46/3
[195] Digital input
x46/5
[196] Digital input
x46/7
[197] Digital input
x46/9
[198] Digital input
x46/11
[199] Digital input
x46/13
NOTICE
[222] Homing OK
This option is available only with
software version 48.20 and newer.
Homing is completed with the selected
homing function
(parameter 17-80 Homing Function).
NOTICE
[223] On Target
This option is available only with
software version 48.20 and newer.
Positioning is completed and the on
target signal is sent when the actual
position is within parameter 3-05 On
Reference Window for the duration of
parameter 3-09 On Target Time and the
actual speed does not exceed
parameter 3-05 On Reference Window.
NOTICE
[224] Position Error
This option is available only with
software version 48.20 and newer.
The position error exceeds the value in
parameter 4-71 Maximum Position Error for
the time set in parameter 4-72 Position
Error Timeout.
NOTICE
[225] Position Limit
This option is available only with
software version 48.20 and newer.
The position is outside the limits set in
parameter 3-06 Minimum Position and
parameter 3-07 Maximum Position.
