Parameter Descriptions
0-24 Display Line 3 Large
Option:
[1827] Safe Opt. Est. Speed
[1828] Safe Opt. Meas. Speed
[1829] Safe Opt. Speed Error
3 3
[1836] Analog Input X48/2 [mA]
[1837] Temp. Input X48/4
[1838] Temp. Input X48/7
[1839] Temp. Input X48/10
[1843] Analog Out X49/7
[1844] Analog Out X49/9
[1845] Analog Out X49/11
[1860] Digital Input 2
[1870] Mains Voltage
[1871] Mains Frequency
[1872] Mains Imbalance
[1875] Rectifier DC Volt.
[1890] Process PID Error
[1891] Process PID Output
[1892] Process PID Clamped Output
[1893] Process PID Gain Scaled Output
[2316] Maintenance Text
[3019] Wobble Delta Freq. Scaled
[3110] Bypass Status Word
[3111] Bypass Running Hours
[3401] PCD 1 Write to MCO
[3402] PCD 2 Write to MCO
[3403] PCD 3 Write to MCO
[3404] PCD 4 Write to MCO
[3405] PCD 5 Write to MCO
[3406] PCD 6 Write to MCO
[3407] PCD 7 Write to MCO
[3408] PCD 8 Write to MCO
[3409] PCD 9 Write to MCO
[3410] PCD 10 Write to MCO
[3421] PCD 1 Read from MCO
[3422] PCD 2 Read from MCO
[3423] PCD 3 Read from MCO
[3424] PCD 4 Read from MCO
[3425] PCD 5 Read from MCO
[3426] PCD 6 Read from MCO
[3427] PCD 7 Read from MCO
[3428] PCD 8 Read from MCO
[3429] PCD 9 Read from MCO
[3430] PCD 10 Read from MCO
[3440] Digital Inputs
[3441] Digital Outputs
[3450] Actual Position
[3451] Commanded Position
[3452] Actual Master Position
[3453] Slave Index Position
[3454] Master Index Position
[3455] Curve Position
[3456] Track Error
36
®
VLT AutomationDrive FC 301/302
0-24 Display Line 3 Large
Function: Option:
[3457]
[3458]
[3459]
[3460]
[3461]
[3462]
[3464]
[3465]
[3466]
[3470]
[3471]
[4235]
[4282]
[4283]
[4285]
[4286]
[9913]
[9914]
[9917]
[9918]
[9919]
[9920]
[9921]
[9922]
[9923]
[9924]
[9952]
[9953]
[9954]
[9961]
[9962]
[9963]
[9964]
[9965]

0-25 My Personal Menu

Range:
Size
related
Danfoss A/S © 10/2018 All rights reserved.
Synchronizing Error
Actual Velocity
Actual Master Velocity
Synchronizing Status
Axis Status
Program Status
MCO 302 Status
MCO 302 Control
SPI Error Counter
MCO Alarm Word 1
MCO Alarm Word 2
S-CRC Value
Safe Control Word
Safe Status Word
Active Safe Func.
Safe Option Info
Idle time
Paramdb requests in queue
tCon1 time
tCon2 time
Time Optimize Measure
Fan Ctrl deltaT
Fan Ctrl Tmean
Fan Ctrl NTC Cmd
Fan Ctrl i-term
Rectifier Current
PC Debug 0
PC Debug 1
PC Debug 2
FPC Debug 0
FPC Debug 1
FPC Debug 2
FPC Debug 3
FPC Debug 4
Function:
[0 - Define up to 50 parameters to appear in the
9999 ] Q1 Personal Menu, accessible via the [Quick
*
Menu] key on the LCP. The parameters are
shown in the Q1 Personal Menu in the order
they are programmed into this array
parameter. Delete parameters by setting the
value to 0000.
For example, this can be used to provide
quick, simple access to just 1 or up to 50
parameters, which require changing on a
regular basis (for example, for plant
maintenance reasons) or by an OEM to
enable simple commissioning of their
equipment.
