Parameter Lists
16-10 Power [kW]
16-11 Power [hp]
16-12 Motor Voltage
16-13 Frequency
16-14 Motor current
16-15 Frequency [%]
16-16 Torque [Nm]
16-17 Speed [RPM]
16-18 Motor Thermal
16-19 Thermistor Sensor Temperature
16-20 Motor Angle
16-21 Torque [%] High Res.
16-22 Torque [%]
16-23 Motor Shaft Power [kW]
16-24 Calibrated Stator Resistance
16-25 Torque [Nm] High
16-28 Angle Error
16-3* Drive Status
16-30 DC Link Voltage
16-31 System Temp.
16-32 Brake Energy /s
16-33 Brake Energy Average
16-34 Heatsink Temp.
16-35 Inverter Thermal
16-36 Inv. Nom. Current
16-37 Inv. Max. Current
16-38 SL Controller State
16-39 Control Card Temp.
16-40 Logging Buffer Full
16-41 Performance Measurements
16-42 Service Log Counter
16-43 Timed Actions Status
16-44 Speed Error [RPM]
16-45 Motor Phase U Current
16-46 Motor Phase V Current
16-47 Motor Phase W Current
16-48 Speed Ref. After Ramp [RPM]
16-49 Current Fault Source
16-5* Ref. & Feedb.
16-50 External Reference
16-51 Pulse Reference
16-52 Feedback[Unit]
16-53 Digi Pot Reference
16-57 Feedback [RPM]
16-6* Inputs & Outputs
16-60 Digital Input
16-61 Terminal 53 Switch Setting
16-62 Analog Input 53
16-63 Terminal 54 Switch Setting
16-64 Analog Input 54
16-65 Analog Output 42 [mA]
16-66 Digital Output [bin]
16-67 Freq. Input #29 [Hz]
16-68 Freq. Input #33 [Hz]
16-69 Pulse Output #27 [Hz]
MG33MP02
Programming Guide
0 kW All set-ups
0 hp All set-ups
0 V All set-ups
0 Hz All set-ups
0 A All set-ups
0 % All set-ups
0 Nm All set-ups
0 RPM All set-ups
0 % All set-ups
0 °C All set-ups
0 N/A All set-ups
0 % All set-ups
0 % All set-ups
0 kW All set-ups
0.0000 Ohm All set-ups
0 Nm All set-ups
0 ° All set-ups
0 V All set-ups
0 °C All set-ups
0 kW All set-ups
0 kW All set-ups
0 °C All set-ups
0 % All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
0 N/A All set-ups
0 °C All set-ups
[0] No All set-ups
0 N/A All set-ups
0 N/A All set-ups
[0] Timed Actions Auto All set-ups
0 RPM All set-ups
0 A All set-ups
0 A All set-ups
0 A All set-ups
0 RPM All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 ReferenceFeedbackUnit All set-ups
0 N/A All set-ups
0 RPM All set-ups
0 N/A All set-ups
[0] Current All set-ups
0 N/A All set-ups
[0] Current All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
