Parameter Descriptions

1-20 Motor Power [kW]

Range: Function:
NOTICE
Size [ 0.09 -
related 3000.00
*
This parameter cannot be adjusted
kW]
while the motor is running.
Enter the nominal motor power in kW
according to the motor nameplate data.
The default value corresponds to the
nominal rated output of the frequency
converter.
This parameter is visible in the LCP if
parameter 0-03 Regional Settings is set to
[0] International.
1-21 Motor Power [HP]
Range: Function:
Size [ 0.09 - Enter the nominal motor power in hp
related 3000.00 according to the motor nameplate data.
*
hp] The default value corresponds to the
nominal rated output of the unit. This
parameter is visible in the LCP if
parameter 0-03 Regional Settings is [1] US.
1-22 Motor Voltage
Range: Function:
Size [ 10 - Enter the nominal motor voltage
related 1000 V] according to the motor nameplate
*
data. The default value corresponds to
the nominal rated output of the unit.
1-23 Motor Frequency
Range: Function:
NOTICE
Size [20 -
related 1000
*
From software version 6.72 onwards,
Hz]
the output frequency of the frequency
converter is limited to 590 Hz.
Select the motor frequency value from the
motor nameplate data. If a value other than
50 Hz or 60 Hz is selected, adapt the load-
independent settings in parameter 1-50 Motor
Magnetisation at Zero Speed to
parameter 1-53 Model Shift Frequency. For
87 Hz operation with 230/400 V motors, set
the nameplate data for 230 V/50 Hz. To run at
87 Hz, adapt parameter 4-13 Motor Speed High
Limit [RPM] and parameter 3-03 Maximum
Reference.
MG33MP02
Programming Guide
1-23 Motor Frequency
Range:
50 [20 -
*
1000
Hz]
1-24 Motor Current
Range:
Size
related
*

1-25 Motor Nominal Speed

Range:
Size
related
*

1-26 Motor Cont. Rated Torque

Range:
Size
related
*
1-29 Automatic Motor Adaptation (AMA)
Option:
Danfoss A/S © 10/2018 All rights reserved.
Function:
NOTICE
The default range for the parameter is only
available for software version 8.23.
From software version 6.72 onwards, the
output frequency of the frequency
converter is limited to 590 Hz.
Select the motor frequency value from the motor
nameplate data. If a value other than 50 Hz or 60
Hz is selected, adapt the load-independent settings
in parameter 1-50 Motor Magnetisation at Zero
Speed to parameter 1-53 Model Shift Frequency. For
87 Hz operation with 230/400 V motors, set the
nameplate data for 230 V/50 Hz. To run at 87 Hz,
adapt parameter 4-13 Motor Speed High Limit [RPM]
and parameter 3-03 Maximum Reference.
Function:
[ 0.10 - Enter the nominal motor current
10000.00 A] value from the motor nameplate
data. The data is used for
calculating torque, motor overload
protection, and so on.
Function:
[10 - 60000 Enter the nominal motor speed
RPM] value from the motor nameplate
data. The data is used for calculating
motor compensations. n
n .
slip
Function:
[0.1 - Enter the value from the motor
100000.0 nameplate data. The default value
Nm] corresponds to the nominal rated
output. This parameter is available when
parameter 1-10 Motor Construction is set
to [1] PM, non-salient SPM, that is the
parameter is valid for PM and non-
salient SPM motors only.
Function:
NOTICE
This parameter cannot be adjusted while
the motor is running.
The AMA function optimizes dynamic motor
performance by automatically optimizing the
advanced motor parameters
(parameter 1-30 Stator Resistance (Rs) to
3 3
= n -
m,n s
