17-34 HIPERFACE Baudrate

Option:
NOTICE
This parameter cannot be adjusted while the
motor is running.
3 3
Select the baud rate of the attached encoder.
The parameter is only accessible when
parameter 17-20 Protocol Selection is set to [1]
HIPERFACE.
[0] 600
[1] 1200
[2] 2400
[3] 4800
[4] 9600
*
[5] 19200
[6] 38400

3.17.3 17-5* Resolver Interface

This parameter group is used for setting parameters for the
®
VLT Resolver Input MCB 103.
Usually, the resolver feedback is used as motor feedback
from permanent magnet motors with parameter 1-01 Motor
Control Principle set to [3] Flux w/motor feedback.
Resolver parameters cannot be adjusted while the motor is
running.
17-50 Poles
Range:
2 [2 - 8 ] Set the pole number on the resolver. The value is
*
17-51 Input Voltage
Range:
7 V [2 - 8 V] Set the input voltage to the resolver. The
*
17-52 Input Frequency
Range:
10 kHz [2 - 15 kHz] Set the input frequency to the resolver.
*
17-53 Transformation Ratio
Range:
0.5 [0.1 - 1.1 ] Set the transformation ratio for the resolver.
*
218
Function:
Function:
stated in the datasheet for resolvers.
Function:
voltage is stated as RMS value. The value is
stated in the datasheet for resolvers.
Function:
The value is stated in the datasheet for
resolvers.
Function:
The transformation ratio is:
V
out
T
ratio =
V
in
The value is stated in the datasheet for
resolvers.
Danfoss A/S © 10/2018 All rights reserved.
®
VLT AutomationDrive FC 301/302

17-56 Encoder Sim. Resolution

Set the resolution and activate the encoder emulation function
(generation of encoder signals from the measured position from
a resolver). Use this function to transfer the speed or position
information from 1 frequency converter to another. To disable
the function, select [0] Disabled.
Option:
[0]
*
[1]
[2]
[3]
[4]
17-59 Resolver Interface
Activate the VLT® Resolver Input MCB 103 when the resolver
parameters are selected. To avoid damage to resolvers, adjust
parameter parameter 17-50 Poles parameter 17-53 Transformation
Ratio before enabling this parameter.
Option:
[0]
*
[1]

3.17.4 17-6* Monitoring and Application

This parameter group is for selecting extra functions when
®
VLT Encoder Input MCB 102 or VLT
103 is fitted into option slot B as speed feedback.
Monitoring and application parameters cannot be adjusted
while the motor is running.
17-60 Feedback Direction
Option:
[0] Clockwise
*
[1] Counter
clockwise
17-61 Feedback Signal Monitoring
Select which action the frequency converter should take if a
faulty encoder signal is detected. The encoder function in
parameter 17-61 Feedback Signal Monitoring is an electrical
check of the hardware circuit in the encoder system.
Option:
[0]
[1]
*
[2]
[3]
[4]
Function:
Disabled
512
1024
2048
4096
Function:
Disabled
Enabled
®
Resolver Input MCB
Function:
NOTICE
This parameter cannot be adjusted
while the motor is running.
Change the detected encoder rotation
direction without changing the wiring to
the encoder.
Function:
Disabled
Warning
Trip
Jog
Freeze Output
