Parameter Descriptions
8-17 Configurable Alarm and Warningword
The configurable alarm and warning word has 16 bits (0–15).
Each of those bits can be configured to any of the following
options.
Option:
3 3
[10073]
[10074]
[10075]
[10078]
[10079]
[10081]
[10082]
[10084]
[10090]
[10091]
[10164]
[10166]
8-19 Product Code
Range:
Size [0 -
related 2147483647 ]
*

3.9.3 8-3* FC Port Settings

8-30 Protocol
Option:
[0] FC
*
[1] FC MC
[2] Modbus RTU
8-31 Address
Range:
1 [ 1 - 247 ] Enter the address for the frequency converter
*
8-32 FC Port Baud Rate
Option:
[0] 2400 Baud
[1] 4800 Baud
[2] 9600 Baud
[3] 19200 Baud
[4] 38400 Baud
[5] 57600 Baud
[6] 76800 Baud
[7] 115200 Baud
160
Safestop auto restart alarm
PTC thermistor alarm
Illegal profile alarm
Tracking error alarm
Illegal PS config alarm
CSIV corrupt alarm
CSIV param error alarm
No safety option alarm
Feedback monitor alarm
AI54 settings alarm
ATEX ETR current lim alarm
ATEX ETR freq limit alarm
Function:
Select 0 to read out the actual
fieldbus product code according
to the mounted fieldbus option.
Select 1 to read out the actual
vendor ID.
Function:
Select the protocol to be used. Changing
protocol is not effective until after powering
off the frequency converter.
Function:
(standard) port.
Valid range: Depends on selected protocol.
Function:
Baud rate selection for the FC (standard) port.
Danfoss A/S © 10/2018 All rights reserved.
®
VLT AutomationDrive FC 301/302
8-33 Parity / Stop Bits
Option:
[0]
*
[1]
Function:
[2]
[3]

8-34 Estimated cycle time

Range:
0 ms
*
1000000 ms]
8-35 Minimum Response Delay
Range:
10 ms
*
8-36 Max Response Delay
Range:
Size
related
*
8-37 Max Inter-Char Delay
Range:
Size
related
*

3.9.4 8-4* FC MC Protocol Set

8-40 Telegram Selection

Option:
[1] Standard telegram 1 Enables use of freely configurable
*
[100] None
[101] PPO 1
[102] PPO 2
[103] PPO 3
[104] PPO 4
Even Parity, 1 Stop Bit
Odd Parity, 1 Stop Bit
No Parity, 1 Stop Bit
No Parity, 2 Stop Bits
Function:
[0 - In noisy environments, the interface may
be blocked due to overload or bad frames.
This parameter specifies the time between
2 consecutive frames on the network. If the
interface does not detect valid frames in
that time, it flushes the receive buffer.
Function:
[ 1 - 10000 Specify the minimum delay time
ms] between receiving a request and
transmitting a response. This is used for
overcoming modem turnaround delays.
Function:
[ 11 - Specify the maximum allowed delay
10001 ms] time between transmitting a request
and receiving a response. If a response
from the frequency converter is
exceeding the time setting, then it is
discarded.
Function:
[ 0.00 - Specify the maximum allowed time
35.00 ms] interval between receipt of 2 bytes. This
parameter activates timeout if
transmission is interrupted.
This parameter is active only when
parameter 8-30 Protocol is set to [1] FC MC
protocol.
Function:
telegrams or standard telegrams for
the FC port.
Function:
