Parameters
16-11 Power [hp]
Range: Function:
0 hp [0 - 1000 hp] View the DC link power in hp. The value
*
shown is calculated on the basis of the
actual motor voltage and motor current.
16-12 Motor Voltage
Range: Function:
0 V [0 - 65535 V] View the motor voltage, a calculated value
*
used for controlling the motor.
16-13 Frequency
Range: Function:
0 Hz [0 - 6553.5 Hz] View the motor frequency, without
*
resonance dampening.
16-14 Motor current
Range: Function:
0 A [0 - 655.35 A] View the motor current measured as a
*
mean value, IRMS.
16-15 Frequency [%]
Range:
0 % [0 - 6553.5 %]
*
16-18 Motor Thermal
Range:
0 % [0 - 100 %]
*

3.12.3 16-3* Drive Status

16-30 DC Link Voltage
Range:
0 V [0 - 65535 V]
*
16-34 Heatsink Temp.
Range:
0 °C [0 - 255 °C]
*
16-35 Inverter Thermal
Range:
0 % [0 - 255 %]
*
16-36 Inv. Nom. Current
Range: Function:
0 A [0 - 655.35 A] View the inverter nominal current, which
*
should match the nameplate data on the
connected motor. The data are used for
motor protection, etc.
®
VLT HVAC Basic Drive Programming Guide
Function:
Function:
Function:
View a measured value.
Function:
Function:
®
MG18B222 - VLT is a registered Danfoss trademark
16-37 Inv. Max. Current
Range: Function:
0 A [0 - 655.35 A] View the inverter maximum current. The
*
data are used for calculation of adjustable
frequency drive protection, etc.
16-38 SL Controller State
Range: Function:
0 [0 - 20 ] View the actual state of the Smart Logic
*
Controller (SLC).
3.12.4 16-5* Ref. & Feedb.
16-50 External Reference
Range:
0 % [-200 - 200 %]
*
16-52 Feedback[Unit]
Range:
0 ProcessCtrlUnit [-4999 - 4999
*
ProcessCtrlUnit]

3.12.5 16-6* Inputs and Outputs

16-60 Digital Input
Range: Function:
0 [0 - 65535 ] View actual state of the digital inputs 18, 19,
*
27 and 29.
Bits definition
Bit 0
Bit 1
Bit 2
Bit 3
Bit 4
Bit 5
Bit 6~15
Table 3.10
16-61 Terminal 53 Setting
Option: Function:
View the setting of input terminal 53. Current
= 0; Voltage = 1.
[0] Current mode
[1] Voltage mode
Function:
Function:
View the feedback
resulting from the
selection of scaling in
3-02 Minimum Reference
and 3-03 Maximum
Reference.
Unused
Unused
Digital input term. 29
Digital input term. 27
Digital input term. 19
Digital input term. 18
Unused
3-55
