16-11 Power [hp]
Range:
0.00 hp [0.00 - 1000.00
*
hp]
3 3
16-12 Motor Voltage
Range:
0.0 V [0.0 - 65535.0 V] View the motor voltage, a calculated
*
16-13 Frequency
Range:
0.0 Hz [0.0 - 6553.5 Hz] View the motor frequency, without
*
16-14 Motor Current
Range:
0.00 A [0.00 - 655.35 A] View the motor current measured as a
*
16-15 Frequency [%]
Range:
0.0 % [0.0 - 6553.5
*
%]
16-18 Motor Thermal
Range:
0.0 % [0.0 - 100.0
*
%]

3.12.3 16-3* Drive Status

16-30 DC Link Voltage
Range:
0 V [0 - 65535 V]
*
16-34 Heatsink Temp.
Range:
0 C [0 - 255 C] View the temperature of the frequency
*
64
VLT HVAC Basic Drive Programming Guide
Function:
View the DC link power in hp. The
value shown is calculated on the basis
of the actual motor voltage and motor
current.
Function:
value used for controlling the motor.
Function:
resonance dampening.
Function:
mean value, IRMS.
Function:
View a two-byte word reporting the actual
motor frequency (without resonance
dampening) as a percentage (scale
0000-4000 Hex) of 4-19 Max Output
Frequency.
Function:
View the calculated motor temperature in
percentage of allowed maximum. At 100% a
trip will occur, if selected in 1-90 Motor
Thermal Protection. The basis for the
calculation is the ETR function selected in
1-90 Motor Thermal Protection.
Function:
View a measured value.
Function:
converters heat sink.
MG.18.B1.02 - VLT
16-35 Inverter Thermal
Range:
0.0 % [0.0 - 255.0 %] View the percentage of thermal load on
*
16-36 Inv. Nom. Current
Range:
0.0 A [0.0 - 655.35 A] View the inverter nominal current, which
*
16-37 Inv. Max. Current
Range:
0.0 A [0.0 - 655.35 A] View the inverter maximum current. The
*
16-38 SL Controller State
Range: Function:
0 [0 - 255 ] View the actual state of the Smart Logic Controller
*
(SLC).
3.12.4 16-5* Ref. & Feedb.
16-50 External Reference
Range:
0.0 % [-200.0 - 200.0 %] View the total reference, the sum of
*
16-52 Feedback[Unit]
Range:
0.0
ProcessCtrlUnit ProcessCtrlUnit]
*
®
is a registered Danfoss trademark
Function:
the frequency converter. At 100% a trip
will occur.
Function:
should match the nameplate data on the
connected motor. The data are used for
motor protection, etc.
Function:
data are used for calculation of
frequency converter protection, etc.
Function:
digital, analog, preset, bus and freeze
references.
Function:
[-4999.0 - 4999.0 View the feedback
resulting from the
selection of scaling in
3-02 Minimum Reference
and 3-03 Maximum
Reference.
