DETAILED DESCRIPTION OF ERROR MESSAGES
E 16.n Attached scaler electronics is of new type
E 17, 18 reserved

3.3 Control panel related error messages

E 19.n Control panel is of new type
E 20.n Control panel key is stuck during selftest
E 21, 22 reserved

3.4 Instrument related error messages

E 23
to the socket
E 25
version F or later
E 24, 26, 27 reserved
Technical Manual
The recently attached scaler electronics module cannot be used since the current version of
the software on the MCB does not have up-to-date information. All other functions are in use,
except for the new scaler. Update the MCB software.
E 16.1 New type of scaler electronics is attached to MCB
E 16.2 New type of scaler electronics is attached to IMUX
The recently attached new control panel is of a new type and cannot be controlled. Please
also update the MCB software. Then decimal "n" indicates which control panel is of the new
type.
E 19.1 Control panel in branch 1 is of new type
E 19.2 reserved (Control panel in branch 2 is of new type)
When the power is turned on the unit checks that no keys are pressed in the control panel(s).
The decimal "n" indicates which control panel(s) has the failed key.
E 20.1 Control panel 1 key stuck
E 20.2 Control panel 2 key stuck
Polymerization light bulb is blown or not properly attached
The MCB monitors the current flowing from the IPS to the curing light bulb. If the current is
abnormally small then this error is generated. Check the bulb and the condition of the bulb
socket. Some lights (LYSTA) have in series with the bulb connected a temperature fuse, that
might have triggered (overheating). Check also the condition of the quick-connector pins. If it
still does not come on, check that the micromotor or the scaler operates to make sure that the
cables in the arm between the MCB and IMUX are OK.
Satelec mini L.E.D. polymerization light requires IMUX PCB
The usage of the Satelec mini L.E.D. requires the IMUX PCB version F or later.
