Chapter
E
NOTE The preventive maintenance should be performed once a year by a qualified
service technician.

1 DELIVERY ARMS

OP delivery arm
•
•
Side delivery arm
•

2 SUCTION ARMS

Ergo suction arm
•
Adjustable suction arm
•
Technical Manual
PREVENTIVE MAINTENANCE
Arm friction. Adjust if needed, refer to section 1.2 "Adjusting friction of the OP delivery arm
joints" on page F-2.
Arm balance. Adjust if needed, refer to section 1.3 "Adjusting balance of the OP delivery
arm" on page F-3.
Arm frictions. Adjust if needed, refer to sections 1.5 "Adjusting the side delivery arm base
joint friction" on page F-10, 1.6 "Adjusting the friction of the side delivery arm joint" on
page F-10, 1.7 "Adjusting the side delivery arm instrument console friction" on page F-11
and 1.8 "Adjusting the lifting friction of the side delivery arm" on page F-11.
Arm friction. Adjust if needed, refer to section 1.10 "Adjusting friction of the ergo suction
arm" on page F-15.
Arm friction. Adjust if needed, refer to section 1.11 "Adjusting friction of the adjustable suc-
tion arm" on page F-15.
Planmeca Compact i E-1
