Planmeca Compact I Technical Manual page 69

SERVICE MODE DETAILED DESCRIPTION
n 111 Show inputs IN3 (IC39)
n 112 Show inputs IN4
n 113 Show side delivery arm emergency switches signals (0, 1)
n 114 Show bowl position (0, 1)
n 115 Show glass identification signal (0, 1)
n.116 Select glass filling mode (0, 1, 2)
n 117 Show active time of drive air pulse width modulation
n 118 Show active time of spray water pulse width modulation
n 119 Show active time of spray air pulse width modulation
Technical Manual
1st vertical segment (counting from right): WMS use, see service mode 126
2nd: WMS use, see service mode 126
3rd: WMS use, see service mode 125
4th: Bowl above patient chair
5th: Glass recognition
6th: WMS use, see service mode 125
7th: Chair type input 0
8th: Chair type input 1
For factory use.
This service mode is used to check the operation of the up and down emergency stop
switches of the side delivery arm. The display should normally show D0U0 if nothing is touch-
ing the switches (switch closed) and the cable and connectors are OK. Pushing the switches
must change the display to 1 (one) (switch opens). A continuous open circuit in the cables
would also cause the display to show D0U1.
This service mode shows the bowl position. 0 = bowl is not in rest position, the chair cannot
be driven upwards. 1 = bowl is in rest position.
This service mode shows the glass identification signal. 0 = The glass sensor does not iden-
tify the glass and the glass filling is not activated (no water flow). 1 = Glass is in the holder and
glass filling is activated when pressing the glass fill key.
Use this mode to select the glass filling mode. The following settings are possible:
0 = Glass sensor is not used, i.e. the water will flow even if the glass is not in holder.
1 = Glass filling does not start if the glass is not in the holder.
2 = Glass filling starts automatically when the glass is placed to the holder and stops when
the glass is removed or when the filling time runs out.
Factory default is 1.
For factory use.
For factory use.
For factory use.
Chapter C - SERVICE MODE
Planmeca Compact i C-41
