HELP MESSAGES
Help Code
HE 16 The operating light is currently dimmed on pur-
pose.
HE 17 There is no syringe connected to the instru-
ment console.
HE 18 There is no instrument hose connected to this
instrument place (this doriot arm).
HE 19 There is no syringe connected to the connec-
tor located on the cuspidor.
HE 20 The connector located on the cuspidor allows
only a syringe, other instruments can not be
connected to this connector.
HE 21
The flow of both the spray air and spray water
are programmed to zero (no flow).
HE 22 The main air/water valve operation is selected
to be on (n=1) or off (n=0) in the service mode
12 (air)/13 (water). The operation must be
selected to be automatic (n=A).
HE 23
The automatic/manual chip blow can not be
used when the sterile water function is
selected.
HE 24 The selected setting can not be programmed.
HE 25
Planmeca Compact e help message: The
patient chair cannot be driven into the auto-
matic chair position.
HE 26
Compact WE'S help message, should not
appear in Compact i: The chair backrest can-
not be driven down, the seat is too low.
Technical Manual
Meaning
Chapter D - HELP & ERROR MESSAGES
Action or Explanation
This feature enables easier work with compos-
ite materials, minimizing the risk of operating
light induced curing. This feature is triggered
by picking and returning the curing light to its
holder without starting it. The operating light
returns to normal at the same instance any
control is touched or another instrument
selected. The feature can be disabled, see
page C-32 for details.
The console syringe must be re-connected,
otherwise there is an air-leak from the syringe
QC whenever an instrument or device that
requires air pressure is used.
The instrument is picked out, but there is no
hose connected at this location.
The nurse syringe must be re-connected, oth-
erwise there is an air-leak from the nurse
syringe QC whenever an instrument or device
that requires air pressure is used. Install
syringe or disable syringe using service mode
"n.084".
The nurse syringe QC cannot control the cur-
rently connected instrument.
Enter the spray programming mode to set a
flow other than zero, see 4.2 "Instrument spray
flow rates" on page B-4 for details.
This is just a reminder that either of the main
valves is set temporarily to be either always on
or off.
The programming of the selected setting is
disabled. Disable the protection using service
mode "n.000". See page C-17 for details.
Swivel the patient chair with automatic legrest
before driving the chair to the automatic posi-
tion.
Check that the chair type in n.103 is correct.
(refer to chapter "n 103 Show the dental unit
type (nn)" on page C-39)
Drive the seat upwards before lowering the
backrest. If this help message is shown while
the patient chair is attached to the unit, it
means that you have forgotten to switch on the
chair's automatic positions. To clear the mes-
sage, put the operation mode switch on the
cuspidor side of the chair base in the "AUTO"
position (switch up).
