Chapter C - SERVICE MODE
n.107 Triggering level of Er45 adjustment
In this service mode you can adjust the triggering level of Er45 if the low external water pres-
sure is a problem. The default value is 17 which corresponds with the spray water pressure of
1.7 bar. The adjustment range is 1 - 17 in steps of 1.
n.108 Stopping delay for instrument spray air
This service mode is for setting the air flow delay after the water stop on the instrument. Every
step equals to 65 ms more delay.
n.109 Unit type setting to enable or disable the IMUX and the
This service mode is used to enable or disable the IMUX and the door safety features if
needed. Factory default is either 0 or 3 depending on the unit type selection in service
mode 100.
0 = Compact i (nor)
3 = Compact e (Co.E). Door switch ignored.
28 = Cart (CArt). No error messages but text "CArt" displayed if IMUX disconnected.
31 = Independent Cart (In.CA). Door switch ignored and no error messages but text " CArt "
displayed if IMUX disconnected.
44 = No instrument console (noI.C). No error messages nor text " CArt " displayed if IMUX dis-
connected. Glass filling and bowl rinsing get water, assistant syringe gets water and air and
its heater can be powered on and water heater can be powered on even IMUX is discon-
nected.
n 110 Show IC39 outputs
1st vertical segment (counting from right): WMS use
2nd: WMS use
3rd: Factory use
4th: Factory use
5th: Factory use
6th: Factory use
7th: Factory use
8th: Factory use
C-40 Planmeca Compact i
0 = no delay
1= 65 ms
2 = 130 ms
3 = 195 ms
4 = 260 ms (default)
.
.
15 = 975 ms
door features (0, 3, 28, 31, 44, 47)
