Planmeca Compact I Technical Manual page 40

Chapter C - SERVICE MODE
MODE
n 103 Show the dental unit type
n. 104 Instrument multiplexer additional water valve control
n.105 Enable/disable instrument places
n.107 Triggering level of Er45 adjustment
n.108 Stopping delay for instrument spray air
C-12 Planmeca Compact i
Table 11: Other service modes
SERVICE MODE FUNCTION
GENERAL ABOUT THE SERVICE MODE
DISPLAY/RANGE
First digit shows type of Main
PCB:
2 = Planmeca Compact i
Second digit shows IMUX ver-
sion:
0 = no IMUX
1 = IMUX PCB version E or older
2 = IMUX PCB version F-G
(1.08.x)
3 = IMUX PCB version F-G
(1.09.x or 1.10.x)
4 = IMUX PCB version H or never
Third digit shows dental unit type:
0 = Prostyle Compact
1 = Planmeca Compact e
2 = Planmeca Compact i
Fourth digit shows patient chair
type:
0 = no patient chair
1 = Prostyle Compact chair with-
out legrest or legrest up
2 = Prostyle chair with legrest
down
3 = WE'S lifter
4 = Planmeca Compact e chair
5 = Planmeca Compact i chair
with fixed legrest; or automatic
legrest up
6 = Planmeca Compact i chair
with 510 automatic legrest; in
automatic state
7 = Planmeca Compact i chair
with 460 automatic legrest; in
automatic state
8 = Planmeca Compact e with
swivel position recognition and
fixed legrest
9 = Planmeca Compact e with
swivel position recognition and
automatic legrest
A = Planmeca Compact e swiv-
elled to 90° with automatic leg-
rest
0 = disabled (default)
1 = reserved for factory use
2 = enabled
A = automatic
¦¦¦¦¦ ( = all instrument places
enabled, default)
1..17 (17 = default)
0..15 (4 = default)
page
C-39
C-39
C-39
C-40
C-40
