Planmeca Compact I Technical Manual page 143

WMS OPERATION
Cup fill is used, no need to fill bottle.
City Water
Cup fill (water bottle full)
V1 c
V2 c
V5 o
V6 c
Pump not running
Display PCI
Cup fill is used and at same time bottle is filled.
City Water
Cup fill (water level below upper sensor)
V1 o
V2 o
V5 o
V6 c
Pump running
Display PCI
Cup fill is used and at the same time bottle is filled. In city water mode automatic cup fill does
not work.
Automatic cup fill = cup fill key pressed once
Manual cup fill = cup fill key pressed continuously
City Water
Cup fill (water level below lower sensor)
Automatic cup fill Manual cup fill
V1 o
V2 o
V5 c
V6 c
Pump running
Display He 60
Technical Manual
Bottled Water
Cup fill (water bottle full)
V1
V2
V5
V6
Pump
Display
Bottled Water
Cup fill (water level below upper sensor)
V1
V2
V5
V6
Pump
Display
Bottled Water
Cup fill (water level below lower sensor)
o V1
o V2
o V5
c V6
running Pump
He 60 Display
Chapter F - ADJUSTMENTS
c
c
o
c
not running
PCI
c
c
o
c
not running
PCI
Automatic cup fill Manual cup fill
c c
c c
o o
c c
not running not running
He 61 He 61
Planmeca Compact i F-33
