Chapter C - SERVICE MODE
MODE
n.132 Disable beeper sounds
n.133 Operating light mode
n.134 Motorized headrest
n.135 WMS operation
n.136 Disable motorized headrest automatic positions
n.137 Bowl rotation safety features
n.138 Simulation system type
n.139 Duration of long instrument hose flushing
n.140 Suction valve closing time adjustment
n 200 Boot information bits
n 201 Boot software checksum
n 202 Main software checksum
n.203 Processor watchdog test. Restarts the dental unit with
error E 75.1.
n.204 Processor reset test. Restarts the dental unit without
errors.
C-14 Planmeca Compact i
Table 11: Other service modes
SERVICE MODE FUNCTION
GENERAL ABOUT THE SERVICE MODE
DISPLAY/RANGE
0 = beeper on (default)
1 = beeper disabled
0 = not installed (even buttons do
not work)
1 = installed (no errors from bulb
burned out) (default)
2 = installed with errors from bulb
burned out (shows E 58).
0 = not installed (will show error
E80.2 if it is installed)
1 = installed (will show E80.1 if it
is not installed)
2 = automatic recognition of
headrest (default)
0 = disabled totally (no operation,
no error messages)
1 = not installed (will show error
E63.1 if it is installed)
2 = installed (will show error
E63.2 if it is not installed)
3 = automatic WMS recognition.
Default is 3 (automatic WMS rec-
ognition).
0 = Automatic positions enabled
(default)
1 = Automatic positions disabled
0 = Bowl roation is not included in
the safety circuit
1 = Bowl roation is included in the
safety circuit (default)
0 = IDSS - Interactive Digital Sim-
ulation System
1 = ASW-1 - Advanced Simula-
tion Workplace Single (Main
Valves are in normal use)
2 = ASW-N - Advanced Simula-
tion Workplace (Main Valves are
not in use)
2 - 9 minutes.
(default 2 minutes)
0 - 3 seconds
(default is 0)
For factory use
For factory use
For factory use
page
C-44
C-44
C-44
C-44
C-45
C-45
C-45
C-45
C-45
C-45
C-45
C-45
C-45
