Planmeca Compact I Technical Manual page 80

Chapter D - HELP & ERROR MESSAGES
Help Code
HE 3 The patient chair cannot be driven down
because the emergency switch is activated.
HE 4 This left-hand instrument position allows only
a syringe.
HE 5 This instrument position does not accept a
syringe.
HE 6
The patient chair cannot be driven when an
instrument is in use.
HE 7
The patient chair up/down movement is not
allowed when the cuspidor door is open. Only
the manual backrest movement is allowed.
HE 8 The seat height can not be programmed this
high in automatic positions for patient safety
reasons.
HE 9
This scaler cannot currently be used with this
unit.
HE 10 Please wait while configuring the dental instru-
ment setup.
HE 12 The unit's internal error reporting is disabled.
HE 13 The instrument cannot run because of a
patient security violation.
HE 14 This dental instrument is not recognized by the
unit's control system (new type of instrument).
HE 15 This key has no function at this moment.
D-2 Planmeca Compact i
Meaning Action or Explanation
Check that the space under the seat is free
and nothing is touching the plate at the bot-
tom. The chair can be driven normally after the
possible obstruction has been removed.
The leftmost position in the console is
reserved for syringe only. Please replace this
instrument with a syringe. Place the other
instrument to one of the four right-hand
places.
Please remove the syringe from this position
and replace it with any other kind of instru-
ment. The syringe must be placed to the left-
hand place.
Stop the instrument (release the foot pedal) to
be able to run the chair.
Close the cuspidor door to be able to run the
chair up/down or to a pre-programmed posi-
tion.
Please run the chair slightly down to be able to
program this position into memory.
This scaler needs a dedicated electronics that
is not installed, or the scaler electronics
installed is not compatible with this scaler.
Please wait a few seconds for the unit to check
your instrument configuration, since it has
changed.
The unit operates normally but no errors are
reported (exhibition use). Use service mode
15 to turn the error reporting back on. See
page C-20 for details.
Please return the foot control pedal once to
the middle position to start the instrument.
Instruments do not start if the foot control
pedal is already pushed to the right or left
when the instrument is taken out from the
holder.
To be able to operate this new instrument the
MCB software must be updated. See 5.1 "How
to replace/upgrade the software" on page G-
20 for details.
Instruments: Please pick up a dental instru-
ment before attempting to alter its settings; or
if the instrument is selected, this function is not
allowed with this instrument.
Other keys: the unit does not have this func-
tion.
HELP MESSAGES
