WMS OPERATION
When door is open, pump is not running and syringe cannot be used.
City Water
Door open
V1 c
V2 c
V5 c
V6 c
Pump not running
Display door
Syringe no water flow
When suction is used, the main water valve is open to feed water to suction system.
City Water
Suction in use
V1 o
V4 o for 150 ms (from software version
3.07)
When bottle is removed water cannot be used.
City Water
Special situation: bottle removed
SW2 off
V3 c
V2 c
V5 c
Pump not running
Display He 62

6.3 WMS operation, WCS use

Continuously
City Water
SW2 on
V6 c
V7 o
Technical Manual
Bottled Water
Door open
V1 c
V2 c
V5 c
V6 c
Pump not running
Display door
Syringe no water flow
Bottled Water
Suction in use
V1 o
V4 o for 150 ms (from software version
3.07)
Bottled Water
Special situation: bottle removed
SW2 off
V3 c
V2 c
V5 c
Pump not running
Display He 62
Bottled Water
SW2 on
V6 c
V7 o
