SERVICE MODE DETAILED DESCRIPTION
n.84

2.10 MCB CPU direct I/O related service modes (for factory use)

n 85
n 86
n 87
Technical Manual
Set type of extra assistant instrument
Use this service mode to set the type of the (optional) installed assistant instrument (rightmost
location in the suction hose holder and additional holders).
0 = no extra assistant instrument (this location in the holder is available for a suction hose)
1 = assistant's syringe installed
2 = water operated saliva ejector installed
3 = assistant syringe and water operated saliva ejector installed
4 = PM Starlight LED polymerization light
5 = assistant's syringe and PM Starlight
6 = water operated saliva ejector and PM Starlight
7 = assistant's syringe, water operated saliva ejector and PM Starlight
This service mode is also affected automatically by the service mode factory preset.
These service modes are for factory use.
Show IC36 output signals
1st vertical segment (counting from right): WMS use, see service mode 126
2nd: Not in use
3rd: Saliva suction selective valve
4th: High power suction selective valve
5th: Intracam activated
6th: Microvac pulse valve
7th: Main water valve
8th: Glass fill valve
Show IC37 output signals
1st vertical segment (counting from right): Assistant syringe water valve
2nd: Assistant syringe heater
3rd: Metasys/Dürr error acknowledge signal or Dürr VSA rinse valve
4th: Metasys/Microvac/Dürr start signal or Dürr VSA/Wet suction valve
5th: Water flush to suction system
6th: Ejector control
7th: Bowl rinse control
8th: Main air valve
Show IC29 driver signals
1st vertical segment (counting from right): Power source control
2nd: Beeper control
3rd: Boiler control
4th: Assistant call / door open / Intracam control relay
5th: Suction motor relay
6th: Bacrest movement reversion relay
7th: Lift motor movement reversion relay
8th: Instrument reverse rotation
Chapter C - SERVICE MODE
Planmeca Compact i C-35
