Planmeca Compact I Technical Manual page 37

GENERAL ABOUT THE SERVICE MODE
MODE
n 75 Show emergency stop switch signal
n.76 Show lift mechanism position sensor signal
n.77 Show backrest mechanism position sensor signal
n.78 Select S position function mode
n.79 Lift mechanism position sensor calibration mode
n.80 Backrest mechanism position sensor calibration mode
MODE
n 81 Show type of installed suction system
n.82 Set suction motor turn-off delay
n.83 Set number of suction hoses / disable suction system
Technical Manual
Table 8: Patient chair related service modes
SERVICE MODE FUNCTION
Table 9: Separator/suction system related service modes
SERVICE MODE FUNCTION
Chapter C - SERVICE MODE
DISPLAY/RANGE
1 = emergency stop plate acti-
vated
0 = normal
nnn
nnn
0 = previous position remains in
memory when you drive from the
spit position to an automatic posi-
tion
(S key indicator light ON)
(default)
1 = previous position is cleared
from the memory when you drive
from the spit position to an auto-
matic position (S key indicator
light OFF)
L-_ turn axle counterclockwise
L-- ok
–
L- turn axle clockwise
b-_ turn axle counteclockwise
b-- ok
–
b- turn axle clockwise
DISPLAY/RANGE
0 = Wet (or no) suction system
1 = Microvac II (Planmeca)
2 = Dürr Combisep
3 = Metasys
4 = Dürr VSA
5 - 7 = reserved
mm.ss = minutes.seconds
Cont = Continuously on
(default 00.03 = 3 seconds)
0 = no suction system in unit
1 = one suction hose only
2 = two hoses (default)
3 = three hoses (maximum)
Planmeca Compact i C-9
page
C-33
C-33
C-33
C-33
C-33
C-34
page
C-34
C-34
C-34
