Planmeca Compact I Technical Manual page 35

GENERAL ABOUT THE SERVICE MODE
MODE
n 50 Show suction holder type and status for branch 1
n 51 Show suction holder type and status for branch 2
n 52 Show left (high volume) suction sensor signal for branch
1
n 53 Show middle (saliva) suction sensor signal for branch 1
n 54 Show right (ejector) suction sensor signal for branch 1
n 55 Show AUX input signal for branch 1
n 56 Show left (high volume) suction sensor signal for branch
2
n 57 Show middle (saliva) suction sensor signal for branch 2
n 58 Show right (ejector) suction sensor signal for branch 2
n 59 Show AUX input signal for branch 2
MODE
n 60 Show software version in Foot Control CPU
n 61 Show foot control switch signals
n 62 Show pedal horizontal position coordinate
n 63 Show pedal vertical position coordinate
n 64 Show left side sensor signal (unprocessed)
n 65 Show right side sensor signal (unprocessed)
n.66 Select foot control pedal operation mode
n.67 Disable foot control pedal extra functions
n.68 Disable automatic chair positions (A, B, C, D) from foot
control
Technical Manual
Table 5: Suction holder related service modes
SERVICE MODE FUNCTION
Table 6: Foot control related service modes
SERVICE MODE FUNCTION
Chapter C - SERVICE MODE
DISPLAY/RANGE
n.¦¦¦¦; n=type, long= active, short =
in holder
n.¦¦¦¦; n=type, long= active, short =
in holder
0 - 255
0 - 255
0 - 255
0 - 255
0 - 255
0 - 255
0 - 255
0 - 255
DISPLAY/RANGE
n.nn
¦¦ ¦ ¦¦¦¦; JA, JB, AUX, A, B, C, D
±255 (horizontal centre = 0)
±100 (vertical midway = 0)
nnnn
nnnn
0 = normal (default)
1 = instrument control with verti-
cal movement
2 = reversing of micromotor rota-
tion is done with foot control
3 = reversing of micromotor rota-
tion is done with foot control
4 = power limitation selection
done with foot control
1 = normal (all features, default)
0 = no extra functions
0 = manual control on, automatic
positions off
1 = normal (all features, default)
2 = both chair controls off
Planmeca Compact i C-7
page
C-28
C-28
C-28
C-28
C-28
C-28
C-29
C-29
C-29
C-29
page
C-29
C-29
C-30
C-30
C-30
C-30
C-30
C-31
C-31
