Instrument Console; Instruments - Planmeca Compact I Technical Manual

Chapter E - PREVENTIVE MAINTENANCE

3 INSTRUMENT CONSOLE

Oil collector
•
Instrument arms
•
Instrument hoses
•
•
•
•
Control panel
•

4 INSTRUMENTS

Syringe
•
Turbine
•
•
•
•
Micromotor
•
•
•
Polymerization light
•
E-2 Planmeca Compact i
Clean the collector.
Condition of the arms. Replace if needed.
Condition of hoses. Replace if needed.
Condition of quick connectors.
Condition of rubber gasket. Replace if needed.
Check for leaks.
All the keys are working.
Tip is clean.
Drive air pressure. Service mode 30.
Bulb voltage.
O-rings. Change automatically twice a year.
Lubricate.
Bulb voltage.
O-rings. Change automatically twice a year.
Lubricate.
Bulb voltage. Recommended voltages are 8.90 Vdc (Lysta), 15.4 Vdc
(Satelec), 10.0 Vdc (Demetron, PowerLysta).
INSTRUMENT CONSOLE
Technical Manual
