Planmeca Compact I Technical Manual page 64

Chapter C - SERVICE MODE
n 88
1st vertical segment (counting from right): Scaler electronics activated
2nd: Status LED / Run LED control
3rd: Factory use
4th: Factory use
5th: Not in use
6th: Not in use
7th: Not in use
8th: Not in use
n 89
1st vertical segment (counting from right): Microvac overfill error
2nd: Metasys/Dürr functional
3rd: Metasys/Dürr separator alarm or Dürr VSA float reed relay signal
4th: Factory use
5th: Operation light switch
6th: Cuspidor door switch
7th: Metasys separator beeper
8th: Factory use
n 90
1st vertical segment (counting from right): Scaler electronics selection 1
2nd: Scaler electronics selection 2
3rd: Scaler electronics selection 3
4th: Separator selection 1
5th: Separator selection 2
6th: Separator selection 3
7th: WCS container recognition
8th: Patient glass fill button
n 91
1st vertical segment (counting from right): Not in use
2nd: Not in use
3rd: Backrest motor control
4th: Lift motor control
5th: Chair control
n 92
1st vertical segment (counting from right): Factory use
2nd: Emergency switch
3rd: Factory use
C-36 Planmeca Compact i
Show IC31 driver signals
Show IC14 input signals
Show IC16 input signals
Show port A outputs (IC4)
Show port A inputs (IC4)
SERVICE MODE DETAILED DESCRIPTION
Technical Manual
