Chapter F - ADJUSTMENTS
4 WATER MANAGEMENT SYSTEM: ADJUSTING THE
SENSORS
To the sensor surface are marked three circles. The inner area is number 1, the next is 2 an
so on.
Upper sensor adjustment
level (+2/-1 mm)
Lower sensor adjustment
level (±1.5mm)

4.1 Preparations before adjustment

•
•
•
F-28 Planmeca Compact i
Area 1
Open the cuspidor door.
Add some Planosil solution or coloured water (with e.g. caramel) to the container.
Switch on the Clean water mode and switch on the container (bottle) switch.
WATER MANAGEMENT SYSTEM: ADJUSTING THE
Area 2
Area 3
