Chapter F - ADJUSTMENTS

4.2 Adjusting the lower sensor

•
•
•

4.3 Adjusting the upper sensor

•
•
•
F-30 Planmeca Compact i
Switch off the Clean water mode.
Let the pump operate until the water level is in the middle of the area 2 (- 1 / + 2 mm) on
the lower sensor. Switch on the Clean water mode. The plus (+) direction is the water ris-
ing direction.
The sensor adjustment screw is located on the side of the sensor. Adjust the sensor so
that it just recognizes the water level: the sensor light first goes on and then goes off and
remains off.
Switch off the Clean water mode.
Let the pump operate until the water level is at the border between areas 2 and 3 of the
upper sensor (±1.5mm).
The sensor adjustment screw is located on the side of the sensor. Adjust the sensor so
that it just recognizes the water level: the sensor light first goes on and then goes off and
remains off.
WATER MANAGEMENT SYSTEM: ADJUSTING THE
