Planmeca Compact I Technical Manual page 36

Chapter C - SERVICE MODE
MODE
n.69 Momentary spray mode / spray with foot control mode
MODE
n 70 Show operating light button signal
n.71 Set OP-light maximum voltage
n.72 Disable OP-light automatic turn off/on with chair
n.73 Disable OP-light automatic dimming with instrument con-
sole curing lights (not curing light in suction holder)
n.74 Disable OP-light dimming function from its button
C-8 Planmeca Compact i
Table 6: Foot control related service modes
SERVICE MODE FUNCTION
Table 7: Operating light related service modes
SERVICE MODE FUNCTION
GENERAL ABOUT THE SERVICE MODE
DISPLAY/RANGE
0 = momentary spray water off,
instrument spray with foot control
on (default)
1 = momentary spray water on,
instrument spray with foot control
on
2 = momentary spray water off,
instrument spray with foot control
disabled
3 = momentary spray water on,
instrument spray with foot control
disabled
4 = momentary spray disabled,
instrument spray with foot control
on
5 = factory use
6 = momentary spray disabled,
instrument spray with foot control
disabled
7 = factory use
DISPLAY/RANGE
0 = button released
1 = button pressed
nn.n VAC (default 18.5)
1 = synchronized with chair
(default)
0 = completely independent
0 = completely independent
1 = automatic dimming, light
returns to initial brightness when
the polymerization cycle is
stopped (default)
2 = automatic dimming, light
returns to initial brightness when
an another instrument is selected
or operating light key is used.
0 = dimmer function disabled
from OP-light push-button
1 = dimmer function enabled
(default)
2 = dimmer function disabled
from control panel button
3 = dimmer function disabled
page
C-31
page
C-32
C-32
C-32
C-32
C-32
Technical Manual
