Chapter C - SERVICE MODE

1.5 Service mode functions short-form

The following pages list all available service modes as short-form tables. For detailed descrip-
tions of the service modes, please refer to pages indicated in the right column.
The service modes are grouped according to functions into individual tables.
MODE
n.0 Disable programming and limit micromotor speed
n 1 Show software version on MCB
n 2 Show internal unregulated operating voltage
n 3 Show output current of IPS
n 4 Show output voltage of IPS
n 5 Show scaler electronics ID-code
n 6 Show service door switch signal
n 7 Show mains frequency
n 8 Show (optional) assistant syringe hose ID
n 9 Show (optional) assistant syringe hose sense signal
n 10 Show MCB heatsink temperature
n.11 Enable (optional) water heater
n.12 Set main air valve operation
n.13 Set main water valve operation
n.14 Disable automatic functions in S-position
n.15 Disable error messages
C-4 Planmeca Compact i
Table 1: MAIN control system related service modes
SERVICE MODE FUNCTION
GENERAL ABOUT THE SERVICE MODE
DISPLAY/RANGE
0 - 15 (default = 0)
n.nn.n
33.0VDC (±15%), 28.0...38.0 VDC
0.00 - 7.00 A
00.0 - 33.0 VDC
0 = no scaler electronics installed
1 = Amdent
2 = EMS
3 = Satelec
6 = Newtron
4, 5, 7 = reserved
0 = door closed
1 = door open
nn.n Hz (cycles/second)
- = no hose connected
0 = not a syringe
nn = syringe ID code
0 - 255
nn °C (or °F)
1 = enabled (heating on)
- = enabling (10 second delay)
0 = disabled (no heating, default)
1 = always on
A = automatic (default)
0 = always off
1 = always on
A = automatic (default)
0 = always off
0 = no water to cup or cuspidor
1 = flush cuspidor only
2 = fill cup only
3 = fill cup, flush bowl (default)
0 = no error messages are dis-
played
1 = error messages will show
(default)
2 = error messages relating con-
sole arm are not displayed
page
C-17
C-18
C-18
C-18
C-18
C-19
C-19
C-19
C-19
C-19
C-19
C-20
C-20
C-20
C-20
C-20
