Planmeca Compact I Technical Manual page 41

GENERAL ABOUT THE SERVICE MODE
MODE
n.109 Unit type setting to enable or disable the IMUX and the
door features
n 110 Show IC39 outputs
n 111 Show inputs IN3 (IC39)
n 112 Show inputs IN4
n 113 Show side delivery arm emergency switches signals
n 114 Show bowl position
n 115 Show glass identification signal
n.116 Select glass filling mode
n 117 Show active time of drive air pulse width modulation
n 118 Show active time of spray water pulse width modulation
n 119 Show active time of spray air pulse width modulation
n 120 Show active instrument power consumption
n.121 Select the length of the automatic legrest
n.122 Armrest selection
n.123 Factory test
n.124 Set the type of Planmeca Compact i
n 125 Show Water management system status
n 126 Show Water management system inputs and outputs
n.127 Water management system water flow adjustment
n.128 Fake pressure sensor readings
n.129 Adjustment of the upper limit of pre-programmed chair
positions
n.130 Disable WCS
n.131 WCS: adjustment of the syring cleaning solution filling
time
Technical Manual
Table 11: Other service modes
SERVICE MODE FUNCTION
Chapter C - SERVICE MODE
DISPLAY/RANGE
0 = Compact i
1 = Compact e
28 = Cart
31 = Independent Cart
44 = no Instrument Console
For factory use
For factory use
For factory use
---- = no side delivery arm
DxUy; x = downwards switch
y = upwards switch
0 = switch not activated
1 = switch activated
0 = bowl not in rest position
1 = bowl in rest position
0 = glass is not in holder
1 = glass is in holder
0 = no identification
1 = glass identification activated
(default)
2 = automatic glass filling
For factory use
For factory use
For factory use
nn W
0 = 510 (default)
1 = 460
2 = 390
0 = armrests deselected
1 = armrests selected (default)
-
0, 1
nnn
¦¦¦¦¦¦¦¦
0 = normal
1 = fake pressure readings
0 = WCS in use (default)
1 = Starting of WCS disabled
2 = WCS totally disabled
20 - 180, (default = 40)
Planmeca Compact i C-13
page
C-40
C-40
C-41
C-41
C-41
C-41
C-41
C-41
C-41
C-41
C-41
C-42
C-42
C-42
C-42
C-42
C-42
C-43
C-43
C-43
C-43
C-44
